Kubota B26B Tractor Fuse Box Info
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 5A | OPC |
| 2 | 10A | Head light instrument cluster |
| 3 | 20A | Auxiliary |
| 4 | 20A | Flasher / Hazard |
| 5 | 30A | Key stop |
| 6 | 25A | Front work light |
| 7 | 25A | Rear work light |
| Slow blow fuse (is located on the other side of the engine) | ||
| Slow blow fuse | Check circuit against wrong battery connection |
