Kubota Utility Vehicle RTV520 Fuse Box Info
Cabin compartment fuse box location:
The cabin fuse box is located inside the cab under the driver seat.
Fuse Box Diagram | Layout
Cabin compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 20A | Radiator fan motor |
| 2 | 10A | Cooling fan motor |
| 3 | 5A | Horn sw |
| 4 | 10A | Hazard lamp |
| 5 | 10A | ECU |
| 6 | 5A | Aux, back buzzer, combi sw |
| 7 | 15A | Power outlet |
| 8 | 10A | Brake lamp sw, meter |
| 9 | 15A | Work light |
| 10 | 10A | Head light |
| 11 | 10A | Meter, speed meter |
| 12 | 5A | Parking brake lamp, oil pressure lamp, diagnosis lamp |
| 13 | 50A | Key switch |
| 14 | 60A | Key switch |
| 15 | 5A | Spare fuse |
| 16 | 10A | Spare fuse |
| 17 | - | Fuse puller |
| 18 | 15A | Spare fuse |
| 19 | 20A | Spare fuse |
