Citroën C1 2012-2013 Fuse Box Diagram
Fuse box location:
Instrument panel fuse boxes
These are located on each side of the instrument panel under the trim. Turn the steering wheel to the left, remove bolt. Turn the steering wheel to the right (do not forget to release the steering wheel using the key), remove bolt. For the rev counter, partially unscrew bolt located behind it. Raise the instrument panel trim, and the rev counter trim if necessary, to gain access to the fuses located on the left and on the right.
Engine compartment fusebox:
The fusebox is placed in the engine compartment near the battery.
Fuse Box Diagram | Layout
Instrument panel fuses:
| Fuse N° | Rating | Functions |
| 1 | 10 A | Brake lamps - ABS - Electronic gearbox |
| 2 | 25 A | Central locking/unlocking - Remote control |
| 3 | 20 A | Rear screen demisting |
| 4 | 7.5 A | Rear lamps - Number plate lamps - Instrument panel - Screen - headlamp adjustment - LED daytime running lamps - Sidelamps |
| 5 | 7.5 A | Diagnostic socket |
| 6 | 7.5 A | Electronic gearbox - Rear foglamp - ESP - LED daytime running lamps - Instrument panel - Rev counter |
| 7 | - | Not used |
| 8 | 7.5 A | ABS/ESP - Power steering - Fan assembly |
| 9 | 10 A | Reversing lamps - Central locking/unlocking - Electric windows - Rear screen demisting - Speedometer - Air conditioning - Heating - Rev counter - Remote control |
| 10 | 20 A | Front and rear wipers and screenwash |
| 11 | 15 A | Audio equipment - 12 V socket (120 W max) |
| 12 | 7.5 A | Heated rear screen - ABS - Fan assembly - Front and rear wipers and screenwash - Power steering - Central locking/unlocking - Air conditioning - Heating - Electric windows - Speedometer - Rev counter - Remote control - Reversing lamp |
| 13 | 15 A | Airbag - Fuel injection system - Electronic gearbox - Instrument panel - Rev counter - LED daytime running lamps |
| 14 | 7.5 A | Air conditioning - Heating |
| 15* | 40 A | Audio system - 12 V socket - Front and rear wipers - Power steering - ABS/ESP - Cooling fan assembly |
| 16* | 30 A | Electric windows |
| 17* | 40 A | Air conditioning - Heating |
* Fuses located behind the instrument panel. To change them, contact a CITROËN dealer or a qualified workshop.
Engine compartment fusebox:
| Fuse N° | Rating | Functions |
| 1 | 5 A | LED daytime running lamps |
| 2 | 20 A | Front foglamps |
| 3 | 10 A | Left hand front lamp |
| 4 | 10 A | Right hand front lamp |
| 5 | 7.5 A | Electronic gearbox - Fuel injection system |
| 6 | 7.5 A | Electronic gearbox - Fuel injection system |
| 7 | 30 A | LED daytime running lamps - Front foglamps |
| 8 |
25 A 30 A |
ABS ABS/ESP (with VSC) |
| 9 | 30 A | Starter motor - Heated rear screen - ABS - Cooling fan assembly - Front and rear wipers and screenwash - Power steering - Central locking/unlocking - Air conditioning - Heating - Electric windows - Speedometer - Rev counter - Remote control - Reversing lamp - Airbag - Fuel injection system - Electronic gearbox - Instrument panel - LED daytime running lamps |
| 10 | 10 A | Hazard warning lamps - Instrument panel - Rev counter - Direction indicators |
| 11 | 20 A | Left hand front lamp - Right hand front lamp |
| 12 | 15 A | Courtesy lamp - Speedometer - Audio system- Instrument panel - Rev counter |
| 13 | 15 A | Fuel injection system - Cooling fan assembly |
| 14 | 10 A | Horn |
| 15 | 7.5 A | Replacement fuse |
| 16 | 10 A | Replacement fuse |
| 17 | 15 A | Replacement fuse |
| 18 | 50 A | Electronic gearbox |
| 19 | 30 /40 A | Cooling fan assembly |
| 20 |
40 A 50 A |
ABS ABS/ESP (with VSC) |
| 21 | 50 A | Power steering |
