Citroën C5 Aircross 2021 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located at the left side of the steering column at the bottom of the instrument panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box (Upper fuse box):
| Fuse/Relay N° | Rating | Functions |
| 2 | 10A | Heated door mirrors |
| 3 | 40A | Rear one-touch electric windows |
| 5 | 40A | Front one-touch electric windows |
| 6 | 15A | Boot 12 V socket |
| 7 | 30A | Heated front seats |
| 10 | 30A | Panoramic sunroof |
Passenger compartment fuse box (Lower fuse box):
| Fuse/Relay N° | Rating | Functions |
| 4 | 15A | Horn |
| 6 | 20A | Front and rear screenwash pump |
| 7 | 10A | Rear 12 V USB socket |
| 8 | 20A | Rear wiper |
| 10 | 30A | Locking/unlocking of the doors and fuel filler flap |
| 14 | 5A | Alarm (unit) |
| 18 | 5A | Trailer power supply |
| 28 | 5A | Alarm (siren), additional heating/ventilation remote control receiver |
| 29 | 20A | Touch screen (CITROËN Connect Radio or CITROËN Connect Nav) |
| 31 | 10A | Cigarette lighter/front 12 V accessory socket |
| 34 | 5A | Wireless smartphone charger |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 40A | Air conditioning ventilation motor |
| 16 | 20A | Heated windscreen |
| 18 | 10A | Right-hand main beam headlamp |
| 19 | 10A | Left-hand main beam headlamp |
| 24 | 40A | Trailer power supply |
| 26 | 25A | Front foglamps |
