Chevrolet Equinox 2021 Fuse Box Info
Fuse box location:
The instrument panel fuse box is under the instrument panel on the driver side.
Engine compartment fuse box:
Luggage compartment fuse box:
The rear compartment fuse box is behind a trim panel on the side of the rear compartment.
Fuse Box Diagram | Layout
Passenger compartment fuse box:
Fuse/Relay N° | Functions |
01 | DC AC inverter |
02 | Front windows |
03 | Trailer brake |
04 | Heating, ventilation, and air conditioning blower |
05 | Body control module 2 |
06 | Central gateway module |
07 | - |
08 | Body control module 3 |
09 | Amplifier |
10 | - |
11 | - |
12 | - |
13 | - |
14 | - |
15 | Transmission control module |
16 | Front heated seats |
17 | Left data link connector |
18 | Body control module 7 |
19 | Exterior mirror |
20 | Body control module 1 |
21 | Body control module 4 |
22 | Body control module 6 |
23 | Electric steering column lock |
24 | Sensing and diagnostic module |
25 | Occupancy sensor |
26 | - |
27 | Power seats |
28 | Rear windows |
29 | - |
30 | - |
31 | Steering wheel controls |
32 | Body control module 8 |
33 | Heating, ventilation, and air conditioning |
34 | Passive entry, passive start |
35 | Liftgate latch |
36 | Wireless charger module/USB accessory |
37 | Cigarette lighter |
38 | OnStar |
39 | Instrument panel USB |
40 | Camera module/ Liftgate module |
41 | Park assist module/Center stack display/Heating, ventilation and air conditioner display/ Universal garage door opener/Overhead control switchbank |
42 | Radio |
K01 | - |
K02 | Retained accessory power |
K03 | Liftgate |
K04 | - |
K05 | Logistics |
CB1 | - |
CB2 | Auxiliary power outlet console |
Engine compartment fuse box:
Fuse/Relay N° | Functions |
01 | Starter 1 |
02 | Starter 2 |
03 | Lambda sensor 1 |
04 | Engine control module |
05 | FlexFuel sensor/Aero shutter |
06 | Transmission control module |
07 | - |
08 | Engine control module |
09 | Air conditioning clutch |
10 | Canister vent solenoid |
11 | Fuel system |
12 | Front heated seats |
13 | Engine coolant pump |
14 | - |
15 | Lambda sensor 2 |
16 | Ignition coils |
17 | Engine control module |
18 | - |
19 | - |
20 | DC DC converter 2 |
21 | Shift control |
22 | Antilock brake pump |
23 | Front/Rear washer pump |
24 | - |
25 | - |
26 | - |
27 | Antilock brake valves |
28 | LD trailer |
29 | Rear window defogger |
30 | Mirror defroster |
31 | - |
32 | Variable functions |
33 | - |
34 | Horn |
35 | - |
36 | Right high-beam headlamp |
37 | Left high-beam headlamp |
38 | Automatic headlamp leveling |
39 | Fog lamps |
40 | - |
41 | Transmission range control module |
42 | Motorized headlamp |
43 | - |
44 | Interior rearview mirror |
45 | Passenger side ventilated seat |
46 | Driver side ventilated seat |
47 | Steering column lock assembly |
48 | Rear wiper |
49 | - |
50 | Heated steering wheel |
51 | Right daytime running lamp |
52 | Engine control module/ Transmission control |
53 | - |
54 | - |
55 | Front wiper speed/ Control |
56 | - |
57 | Left daytime running lamp |
K01 | Starter solenoid |
K02 | Air conditioning control |
K03 | Engine control module |
K04 | Front wiper control |
K05 | Starter solenoid 2 |
K06 | - |
K07 | - |
K08 | - |
K09 | Front wiper speed |
K10 | - |
K11 | - |
K12 | High-beam headlamps |
K13 | Headlamps/Daytime running lamps |
K14 | Run/Crank |
K15 | Rear window defogger |
Luggage compartment fuse box:
Fuse/Relay N° | Functions |
1 | - |
2 | Liftgate |
3 | Trailer auxiliary power |
4 | Power seat co-driver |
5 | Memory seat module |
6 | Sunroof |
7 | Side blind zone alert |
8 | Trailer reverse lamps |
9 | Rear heated seat 1 |
10 | Park lamps |
11 | Rear heated seat 2 |
12 | - |
13 | Trailer parking lamp |
14 | Right trailer stoplamp/Turn signal lamp |
15 | Left parking lamp |
16 | Right parking lamp |
17 | Video processing module |
18 | Left trailer stoplamp/Turn signal lamp |
19 | All-wheel drive |
20 | Lumbar |
21 | Rear auxiliary power outlet |
22 | Rear drive unit |
K1 | Right trailer stoplamp/Turn signal lamp |
K2 | Trailer reverse lamps |
K3 | Left trailer stoplamp/Turn signal lamp |
K4 | Parking lamps |
K5 | - |
