Chevrolet Equinox 2006 Fuse Box Info
Fuse box location:
The instrument fuse box is located on the passenger’s side of the instrument panel.
Engine compartment fuse box:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay Name | Functions |
| LOCK/MIRROR | Door Lock, Power Mirror |
| CRUISE | Cruise Control System |
| EPS | Electric Power Steering |
| IGN 1 | Switches, Instrument Panel Cluster |
| PRNDL/ PWR TRN | PRNDL/Powertrain |
| BCM (IGN) | Body Control Module |
| AIRBAG | Airbag System |
| BCM/ISRVM | Body Control Module, Inside Rearview Mirror |
| TURN | Turn Signals |
| HTD SEATS | Heated Seats |
| BCM/HVAC | Body Control Module, Heating, Ventilation and Air Conditioning |
| HZRD | Hazard Warning Flashers |
| RADIO | Radio |
| PARK | Parking Lamps |
| BCM/CLSTR | Body Control Module, Instrument Panel Cluster |
| INT LTS/ ONSTAR® | Interior Lights/OnStar® |
| DR LCK | Door Locks |
| PARK LAMP | Parking Lamps Relay |
| HVAC BLOWER | Heating, Ventilation and Air Conditioning Blower Motor |
| DR LCK | Door Locks Relay |
| PASS DR UNLOCK | Passenger Door Unlock Relay |
| DRV DR UNLCK | Driver Door Unlock Relay |
| HEAD LAMP | Headlamps |
Engine compartment fuse box:
| Fuse/Relay Name | Functions |
| HTD SEATS | Heated Seats |
| HVAC BLOWER | Heating, Ventilation, Air Conditioning Blower Control |
| PREM AUD | Premium Audio System, Amplifier |
| ABS PWR | Anti-lock Brake System |
| RR WIPER | Rear Window Wiper |
| FRT WIPER | Front Window Wiper |
| SUNROOF | Sunroof |
| ETC | Electronic Throttle Control |
| PWR WDW | Power Windows |
| A/C CLUTCH | Air Conditioning Clutch |
| EMISS | Emissions |
| ENG IGN | Engine Ignition |
| CIGAR | Cigarette Lighter |
| LH HDLP | Driver’s Side Headlamp |
| COOL FAN HI | Cooling Fan High |
| ECM/TCM | Engine Control Module, Transaxle Control Module |
| AUX OUTLETS | Accessory Power Outlets |
| FUSE PULLER | Fuse Puller |
| INJ | Fuel Injectors |
| PWR TRAIN | Powertrain |
| FUEL PUMP | Fuel Pump |
| A/C DIODE | Air Conditioning Diode |
| TRAILER | Trailer Lighting |
| BRAKE | Brake System |
| RH HDLP | Passenger’s Side Headlamp |
| HORN | Horn |
| BACKUP | Back-up Lamps |
| BATT FEED | Battery |
| ABS | Anti-lock Brake System |
| COOL FAN LO | Cooling Fan Low |
| RR DEFOG | Rear Window Defogger |
| ABS | Anti-lock Brake System |
| FOG LP | Fog Lamps |
| IGN | Ignition Switch |
| ENG MAIN | Engine Relay |
| RR WIPER | Rear Window Wiper Relay |
| FRT WIPER | Front Window Wiper Relay |
| PWR WDW | Power Windows Relay |
| COOL FAN HI | Cooling Fan High Relay |
| WIPER SYSTEM | Wiper System Relay |
| HORN | Horn Relay |
| DRL | Daytime Running Lamps Relay |
| FUEL PUMP | Fuel Pump Relay |
| STARTER RELAY | Starter Relay |
| REAR DEFOG | Rear Window Defogger Relay |
| FOG LP | Fog Lamp Relay |
| COOL FAN LO | Cooling Fan Low Relay |
| A/C CLUTCH | Air Conditioning Clutch Relay |
| POWER SEATS | Power Seats |
