Can-Am Spyder RT Series 2025 Fuse Box Info
Fuse box location:
Fuses are located in the front storage compartment.
Fuse Box Diagram | Layout
Left fuse box:
| Fuse/Relay N° | Rating | Functions |
| Fuses | ||
| 1 | 15A | Cluster / Hazard / DLC |
| 2 | 10A | YRS / VCM / ECM / DESS / PRS / MSR |
| 3 | 10A | Alternator |
| 4 | 20A | Parking brake / Windshield |
| 5 | 5A | ECM |
| 6 | 15A | Injectors / Ignition Coils |
| 7 | 10A | MLS / DLC / TCM /DPS / Cluster / Reverse actuator |
| 8 | 15A | Fuel pump / EVAP / Starter relay / HO2S heaters |
| JCase Fuses | ||
| 1 | 40A | VSS pump |
| 2 | 25A | VSS valves |
| 3 | 40A | DPS |
| 4 | 40A | Main control |
| 5 | - | Not used |
Right fuse box:
| Fuse/Relay N° | Rating | Functions |
| Fuses | ||
| 1 | 15A | Parking lights / Plate lights |
| 2 | 10A | Brake lights / Hazard |
| 3 | 15A | Amplifier |
| 4 | 10A | Trailer module |
| 5 | 7.5A | Headlamps |
| 6 | 5A | GPS_Acc |
| 7 | - | Not used |
| 8 | 15A | Horn |
| JCase Fuses | ||
| 1 | 30A | Cooling fan |
| 2 | 40A | Amplifier / Trailer module |
| 3 | 20A | TCM solenoids |
| 4 | 40A | Headlamps lighting / Horn |
| 5 | 25A | Accessory |
Alternator Circuit Fuse (The fuse holder is located to the LH of the battery):
| Fuse/Relay N° | Rating | Functions |
| 80A | Alternator |
