Opel Rocks-e 2021 Fuse Box Info
Passenger compartment fuse box location:
The fuse boxes are located behind the seats.
Fuse Box Diagram | Layout
Passenger compartment fuse box 1:
| Fuse/Relay N° | Functions |
| 1 | Brake switch |
| 2 | Main computer |
| 3 | Fan |
| 4 | Instrument panel |
| 5 | Battery computer |
| 6 | Horn |
| 7 | Battery drive train / DC / DC converter |
Passenger compartment fuse box 2:
| Fuse/Relay N° | Functions |
| 1 | Steering mounted control |
| 2 | Main computer |
| 3 | Screenwash pump |
| 4 | - |
| 5 | Instrument panel control indicators |
| 6 | - |
| 7 | Motor computer |
| 8 | Brake switch |
| 9 | USB power outlet / lighting for ventilation / heating / demisting buttons / drive selector |
| 10 | - |
| 11 | Diagnostic socket |
| 12 | Wiper motor |
| 13 | Rear left wheel speed sensor |
| 14 | Sidelights front left and rear right / number plate light |
| 15 | Sidelights rear left and front right |
| 16 | Right-hand dipped beam headlight |
| 17 | Left-hand dipped beam headlight |
| 18 | Wiper motor |
