Jeep Commander 2006 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is on the lower instrument panel just to the left of the steering column.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 30A | Audio Amp (B+) |
| 2 | 15A | Sunroof (B+) |
| 3 | 10A | Htd Mirror (EBL) |
| 4 | 20A | Rr Pwr Out (B+) |
| 5 | 10A | Rr HVAC (R/O) |
| 6 | 10A | OCM (B+) |
| 7 | 20A | Door Locks (B+) |
| 8 | 15A | Steer Col Lock (B+) |
| 9 | 20A | Pwr Outlet (B+) |
| 10 | 10A | Ign Run Only Out (R/O) |
| 11 | - | Spare |
| 12 | 10A | Mem. Sw, Courtesy Lamp (B+) |
| 13 | - | Spare |
| 14 | 20A | Cigar Ltr (R/A) |
| 15 | 10A | Tire Press Mon (R/O) |
| 16 | 10A | SCM, Cluster OBD (B+) |
| 17 | 15A | Flipper Glass (B+) |
| 19 | 10A | OCM (R/S) |
| 20 | 10A | WCM, Cluster (R/S) |
| 21 | 15A | Autowipe (Accy Delay) |
| 22 | 15A | Rear Wiper (B+) |
| 24 | 10A | PDC, FCM, A580 (R/S) |
| 25 | 10A | ABS, Trans. Case Switch (R/S) |
| CB1 | 20A | Cycle -Wipers (B+) |
| CB2 | 20A | Non - Cycle Seats (B+) |
| CB3 | 20A | Non - Cycle Windows (Delay) |
Engine compartment fuse box 1 (Power Distribution Center):
| Fuse/Relay N° | Rating | Functions |
| 1 | 40A | HVAC Blower |
| 2 | 30A | Power Outlets |
| 3 | 30A | Rr Wiper/Ign R/O |
| 4 | 30A | ABS Pump |
| 5 | 50A | Cabin Htr 1 (Diesel Only) |
| 6 | 50A | ASD |
| 7 | 30A | Rr HVAC (XK) |
| 8 | 40A | Acc Delay/Seats |
| 9 | - | Spare |
| 10 | 40A | Starter/JB Power |
| 11 | 30A | Cig Ltr/T-Tow |
| 12 | 40A | EBL/Htd Mirror |
| 13 | 40A | JB Power |
| 14 | 7.5A | Cabin Htr 2 (Diesel Only) |
| 15 | 50A | Cabin Htr 3 (Diesel Only) |
| 16 | 25A | IPM/Coils |
| 17 | - | Spare |
| 18 | 20A | TCM/AC Clutch |
| 19 | 20A | Ign Sw |
| 20 | 20A | PCM Batt (Gasoline Only) |
| 21 | 30A | ABS Valves |
| 22 | - | Spare |
| 23 | 20A | FDCM |
| 24 | 20A | Fuel Pump |
| 25 | 20A | FDCM/E-Diff. |
| 26 | 15A | Hyd/PCM (Diesel Only) |
| 27 | 15A | Brake/Stop Lamps |
| 28 | 25A | NGC/Injectors |
| 29 | - | Spare |
| 30 | - | Spare |
| 31 | - | Cabin Htr 1 Rly (Diesel Only) |
| 32 | - | TCM Rly (Gasoline Only) |
| 33 | - | Starter Rly |
| 34 | - | AC Clutch Rly |
| 35 | - | Fuel Pump Rly |
| 36 | - | Cabin Htr 3 Rly (Diesel Only) |
| 37 | - | Horn Rly |
| 38 | - | Cabin Htr 2 Rly (Diesel Only) |
| 39 | - | HVAC Blower Rly |
| 40 | - | ASD Rly |
Engine compartment fuse box 2 (Integrated Power Module):
| Fuse/Relay N° | Rating | Functions |
| 1 | - | Wiper On/Off Rly |
| 2 | - | Wiper Hi/Lo Rly |
| 3 | - | Horn Rly |
| 4 | - | Rear Fog Rly (BUX Only) |
| 5 | - | Lt T-Tow Stop/Turn Rly |
| 6 | - | Rt T-Tow Stop/Turn Rly |
| 7 | - | Park Lamps Rly |
| 8 | 10A | Lt Park Lamps |
| 9 | 10A | T-Tow Park Lamps |
| 10 | 10A | Rt Park Lamps |
| 11 | - | Rad Fan Hi Rly |
| 12 | 20A | FCM Batt #4 |
| 13 | 20A | FCM Batt #2 |
| 14 | 20A | Adjustable Pedal |
| 15 | 20A | Ft Fog Lamps |
| 16 | 20A | Horn |
| 17 | 20A | Rear Fogs |
| 18 | 20A | FCM Batt #1 |
| 19 | 20A | Lt T-Tow Stop/Turn |
| 20 | 20A | FCM Batt #3 |
| 21 | 20A | Rt T-Tow Stop/Turn |
| 22 | 30A | FDCM Mod |
| 23 | 50A | Rad Fan |
| 24 | - | Rad Fan Lo Rly |
| 25 | - | Ft Fog Lamps Rly |
| 26 | - | Adjustable Pedal Rly |
| 27 | 15A | IOD #1 |
| 28 | 20A | IOD #2 (Audio) |
| 29 | 10A | ORC (Ign R/.S) |
| 30 | 10A | ORC (Ign R/O) |
