Ford Thunderbird 1997 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located on the driver's side, under the instrument panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| CIGAR | 20A | Cigar lighter |
| STOP/HAZARD | 15A | Turn/Stop/Hazard lamps |
| CLUSTER | 5A | Instrument cluster |
| ACC | 10A | Warning chime, Radio |
| Wipers | 30A | Interval wiper, Washer |
| OBD II | 10A | Data link connector (DLC) |
| Panel LPS | 5A | Instrument illumination |
| INT LPS | 10A | Instrument illumination, Courtesy lamps |
| POWER WDO | 20A CB | Power windows |
| TURN SIG | 10A | Backup lamps, Turn/Stop/Hazard lamps |
| ANTI-LOCK | 10A | Anti-lock power relay, Anti-lock brake control module |
| PARK LPS | 10A | Exterior lamps |
| AIR BAG | 10A | Air bags |
| A/C | 10A | A/C |
| SEAT/LOCK | 20A CB | Power door locks, Remote keyless entry, Power seats, Anti-theft |
| RUN | 5A | Shift lock, DRL, EVO, ABS, Air bag, Washer fluid level sensor |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 15A | DRL module |
| 2 | 5A | SATC, Power antenna, Digital clock |
| 3 | 20A | Ignition, Constant control relay module (CCRM) |
| 4 | - | Not used |
| 5 | 60A | Constant control relay module (CCRM: EDF & HEDF) |
| 6 | 40A | ABS motor |
| 7 | 60A | Main light switch, Courtesy lamps, RKE module, Integrated control module (ICM), Power mirror, Autolamp, Air bag diagnostic monitor |
| 8 | 20A | ABS module, ABS relay |
| 9 | 60A | Ignition switch |
| 10 | 15A | Horn relay |
| 11 | 15A | Radio |
| 12 | 40A | Radio, Mobile telephone, Multi-function switch, BOO switch, DLC, Cigar lighter, Trunk lid release, RKE, Door locks, Power seats, Anti-theft |
| 13 | 20A | Constant control relay module (CCRM: Fuel pump relay) |
| 14 | 40A | Rear window defrost |
| 15 | 20A | Powertrain control module (PCM) memory, Constant control relay module (CCRM: PCM relay) |
| 16 | - | Not used |
| 17 | 60A | Ignition switch, Blower motor |
| 18 | - | Not used |
