Citroën DS4 2016 Fuse Box

Citroën DS4 2016 Fuse Box Info



Passenger compartment fuse box location:

The fuse box is located at the left side of the steering column at the bottom of the instrument panel, behind the cover.



Engine compartment fuse box location:





Fuse Box Diagram | Layout



Passenger compartment fuse box::

Fuse/Relay N° Rating Functions
    Fuse box 1
8 3A Alarm siren, alarm ECU
13 10A Cigarette lighter / Front 12 V socket
14 10A 12 V socket in boot
16 3A Lighting for the large multifunctional storage unit, rear map reading lamps, glove box illumination
17 3A Sun visor illumination, front map reading lamps
28 15A Audio system, radio (after-market)
30 20A Rear wiper
32 10A Hi-Fi amplifier
    Fuse box 2
36 15A Rear 12 V socket
37 - Not used
38 - Not used
39 - Not used
40 25A 230 V / 50 Hz socket



Engine compartment fuse box:

Fuse/Relay N° Rating Functions
19 30A Windscreen wipers slow/fast speed
20 15A Front and rear screenwash pump
21 20A Headlamp wash pump
22 15A Horn
23 15A Right-hand main beam headlamp
24 15A Left-hand main beam headlamp
27 5A Left-hand dipped headlamp
28 5A Right-hand dipped headlamp
