Chevrolet Cavalier 2001 Fuse Box

Chevrolet Cavalier 2001 Fuse Box Info



Passenger compartment fuse box location:

The instrument panel fuse box is located on the driver side edge of the instrument panel.



Engine compartment fuse box location:





Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay Functions
TURN-B/U Turn Signals, Back-Up Lamps
ERLS Engine Relays
BCM/CLU Body Control Module, Instrument Panel Cluster
PCM Powertrain Control Module
IGN MDL Ignition Module
F/P-INJ Fuel Pump, Fuel Injectors
AIR BG Air Bag
CRUISE Cruise Control Switch
ABS Anti-Lock Brake (Ignition)
Blank Not Used
RFA BATT Remote Keyless Entry System
MIRROR Power Mirror
LT HDLP Left Headlamp
RDO/INTLP Radio, Interior Lamps
RT HDLP Right Headlamp
CLSTR Instrument Panel Cluster
EXT LP Exterior Lamps
CIG Cigarette Lighter, Diagnostic Link Connector
FOG Fog Lamps
HORN Horn
Blank Not Used
Blank Not Used
STOP/HZD Stop Lamps, Hazard Lamps
Blank Not Used
Blank Not Used
RR DEFOG Rear Window Defogger
PWR ACC Power Door Locks, Convertible Top Switch
Blank Not Used
Blank Not Used
Blank Not Used
O2 HTR Oxygen Sensor Heater
HVAC Climate Control System
WIPER Windshield Wiper
BCM Body Control Module
Blank Not Used
PWR WDO Power Windows, Sunroof, Convertible Top (Circuit Breaker)
DRL Daytime Running Lamps (Relay)



Engine compartment fuse box:

Fuse/Relay Functions
IGN Ignition Switch Circuits
BATT 1 Power ACC/Stoplamp Circuits
BATT 2 Lighting Circuits
ABS Anti-Lock Brake System
COOLING FAN Engine Cooling Fan
PCM/HVAC Powertrain Control Module, Heater and A/C Blower
BLO Heater and A/C Blower
PCM Powertrain Control Module
A/C A/C Compressor
ABS/EVO Anti-Lock Brake System
A/C A/C Compressor Relay
FUEL PUMP Fuel Pump Relay
COOLING FAN Engine Cooling Fan Relay
HEATER BLOWER Heater Blower Relay
