Chevrolet Cavalier 1999 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located on the driver side edge of the instrument panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay | Functions |
| TRN-B/L | Exterior Lamps, Back-Up Lamps |
| F/P-INJ | Fuel Pump, Fuel Injectors |
| RR DFOG | Rear Window Defogger |
| CLUSTER | Instrument Cluster, Anti-Lock Brake System |
| CLS/PCM | Instrument Cluster, Powertrain Control Module, Daytime Running Lamps |
| O2 HTR | Rear O2 Sensor Heater |
| WIPER | Windshield Wipers, Windshield Washers |
| ERLS | Automatic Transaxle, Brake Transaxle Shift Interlock (BTSI), A/C Compressor, Cruise Control, Multiport Fuel Injection |
| AIR BAG | Supplemental Inflatable Restraint (SIR) System |
| PWR ACC | Power Door Locks, Convertible Top (Convertible Model Only) |
| EXT LAMP | Exterior Lamps, Instrument Panel Lights |
| HVAC | Heater and A/C Control, Engine Cooling Fan |
| RADIO | Radio, Remote Keyless Entry |
| ALARM | Alarm Module, Interior Lamps, Warning Chimes |
| CRUISE | Cruise Control |
| STOP HAZ | Exterior Lamps, Anti-Lock Brake System, Cruise Control, Turn Signals |
| CIG | Cigarette Lighter |
| INST LPS | Instrument Panel Lights, Warning Chimes |
| PCM/IGN | Powertrain Control Module |
| L HDLP | Left Headlamp, Fog Lamp (Z-24 Model Only) |
| INT LAMP | Alarm Module: Illuminated Entry, Warning Chimes, Overhead Lamps, Map/Reading Lamps, Glove Box Lamp, Trunk Lamp, Radio, Power Mirrors, Remote Keyless Entry |
| IGN | Engine Ignition |
| R HDLP | Right Headlamp, Fog Lamp (Z-24 Model Only) |
| HORN | Horn, Diagnostic Connector |
| PWR WDO/SRF | Power Windows, Power Sunroof, Convertible Top Controls (Convertible Model Only) (Circuit Breaker) |
| DRL | Daytime Running Lamps (Relay) |
Engine compartment fuse box:
| Fuse/Relay | Functions |
| IGN | Ignition Switch Circuits |
| BATT 1 | Power ACC/Stoplamp Circuits |
| BATT 2 | Lighting Circuits |
| ABS | Anti-Lock Brake System |
| COOLING FAN | Engine Cooling Fan |
| BLO | Heater and A/C Blower |
| PCM | Powertrain Control Module |
| A/C | A/C Compressor |
| ABS/EVO | Anti-Lock Brake System |
| A/C | A/C Compressor Relay |
| FUEL PUMP | Fuel Pump Relay |
| COOLING FAN | Engine Cooling Fan Relay |
| ABS | Anti-Lock Brake System Relay |
| HEATER BLOWER | Heater Blower Relay |
