Chevrolet Cavalier 2000 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located on the driver side edge of the instrument panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay | Functions |
| TURN-B/U | Turn Signals, Back-Up Lamps |
| ERLS | Engine Relays |
| BCM/CLU | Body Control Module, Instrument Panel Cluster |
| PCM | Powertrain Control Module |
| IGN MDL | Ignition Module |
| F/P-INJ | Fuel Pump, Fuel Injectors |
| AIR BG | Air Bag |
| CRUISE | Cruise Control Switch |
| ABS | Anti-Lock Brake (Ignition) |
| Blank | Not Used |
| RFA BATT | Remote Keyless Entry System |
| MIRROR | Power Mirror |
| LT HDLP | Left Headlamp |
| RDO/INTLP | Radio, Interior Lamps |
| RT HDLP | Right Headlamp |
| CLSTR | Instrument Panel Cluster |
| EXT LP | Exterior Lamps |
| CIG | Cigarette Lighter, Diagnostic Link Connector |
| FOG | Fog Lamps |
| HORN | Horn |
| Blank | Not Used |
| Blank | Not Used |
| STOP/HZD | Stop Lamps, Hazard Lamps |
| Blank | Not Used |
| Blank | Not Used |
| RR DEFOG | Rear Window Defogger |
| PWR ACC | Power Door Locks, Convertible Top Switch |
| Blank | Not Used |
| Blank | Not Used |
| Blank | Not Used |
| O2 HTR | Oxygen Sensor Heater |
| HVAC | Climate Control System |
| WIPER | Windshield Wiper |
| BCM | Body Control Module |
| Blank | Not Used |
| PWR WDO | Power Windows, Sunroof, Convertible Top (Circuit Breaker) |
| DRL | Daytime Running Lamps (Relay) |
Engine compartment fuse box:
| Fuse/Relay | Functions |
| IGN | Ignition Switch Circuits |
| BATT 1 | Power ACC/Stoplamp Circuits |
| BATT 2 | Lighting Circuits |
| ABS | Anti-Lock Brake System |
| COOLING FAN | Engine Cooling Fan |
| PCM/HVAC | Powertrain Control Module, Heater and A/C Blower |
| BLO | Heater and A/C Blower |
| PCM | Powertrain Control Module |
| A/C | A/C Compressor |
| ABS/EVO | Anti-Lock Brake System |
| A/C | A/C Compressor Relay |
| FUEL PUMP | Fuel Pump Relay |
| COOLING FAN | Engine Cooling Fan Relay |
| HEATER BLOWER | Heater Blower Relay |
