Holden Trax 2016 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located behind the glove box.
Engine compartment fuse box location:
Luggage compartment fuse box location:
The rear compartment fuse box is located in the passenger’s side of the rear compartment.
Fuse Box Diagram | Layout
Passenger compartment fuse box:
Fuse/Relay N° | Functions |
Fuses | |
1 | BCM 1 |
2 | BCM 2 |
3 | BCM 3 |
4 | BCM 4 |
5 | BCM 5 |
6 | BCM 6 |
7 | BCM 7 |
8 | BCM 8 |
9 | DLIS |
10 | SDM B+ |
11 | DLC |
12 | HVAC MDL |
13 | L/GATE RLY |
14 | UPA MDL |
15 | - |
16 | - |
17 | - |
18 | RAIN SNSR |
19 | BCM RVC |
20 | SWC BKLT |
21 | AC APO |
22 | DC APO |
23 | - |
24 | - |
25 | - |
26 | - |
27 | IPC/CMPS MDL |
28 | HDLP SW/DC CVT/CLTCH SW |
29 | - |
30 | - |
31 | IPC B+ |
32 | RDO/CHIME |
33 | - |
34 | - |
S/B01 | - |
S/B02 | - |
S/B03 | PWR WNDW MTR FRT |
S/B04 | - |
S/B05 | LOGISTIC MODE RLY |
S/B06 | - |
S/B07 | PWR WNDW FRT |
S/B08 | PWR WNDW REAR |
Relays | |
RLY1 | ACC/RAP |
RLY2 | L/GATE |
RLY3 | SPARE |
RLY4 | BLOWER |
RLY5 | LOGISTIC MODE |
Engine compartment fuse box:
Fuse/Relay N° | Functions |
Fuses | |
1 | SUNROOF |
2 | OSRVM SW |
3 | - |
4 | SPARE |
5 | EBCM VALVE |
6 | IBS |
7 | SPARE |
8 | TCM B+ |
9 | BCM RVC |
10 | HDLP LEVELING LH/RH |
11 | REAR WIPER |
12 | RR WDW DEFOG |
13 | - |
14 | OSRVM HEAT |
15 | SPARE |
16 | HEATED SEAT MODULE |
17 | TCM R/C |
18 | ECM R/C |
19 | FUEL PUMP |
20 | - |
21 | FAN RLY (AUX BEC) |
22 | - |
23 | IGNITION COIL/INJECTOR COIL |
24 | WASHER PUMP |
25 | - |
26 | CANISTER PURGE SOL/WATER VALVE SOL/TURBO WASTEGATE SOL/ TURBO BYPASS SOL /O2 SENSOR PRE/POST |
27 | SPARE |
28 | - |
29 | ECM PT IGN-1, IGN-2 |
30 | MAF SENSOR |
31 | HIGH BEAM LH |
32 | HIGH BEAM RH |
33 | ECM B+ |
34 | HORN |
35 | A/C CLUTCH |
36 | FRONT FOG LAMP |
FU1 | EBCM PUMP |
FU2 | FRT WIPER |
FU3 | BLOWER |
FU4 | IEC R/C |
FU5 | - |
FU6 | - |
FU7 | SPARE |
FU8 | COOL FAN LOW |
FU9 | COOL FAN HIGH |
FU10 | EVP |
FU11 | STARTER SOL |
Relays | |
1 | RUN CRANK |
2 | FUEL PUMP |
3 | - |
4 | - |
5 | PT RELAY |
6 | COOL FAN HIGH |
7 | STARTER |
8 | COOL FAN LOW |
Engine compartment fuse box (Auxiliary fuse box):
Fuse/Relay N° | Functions |
01 | ELECTRIC VACUUM PUMP RELAY |
02 | COOLING FAN RELAY 1 |
03 | COOLING FAN RELAY 2 |
04 | - |
Luggage compartment fuse box:
Fuse/Relay N° | Functions |
Fuses | |
1 | - |
2 | - |
3 | - |
4 | - |
5 | - |
6 | - |
7 | - |
8 | - |
9 | - |
10 | - |
11 | TRLR MDL |
12 | - |
13 | - |
14 | - |
15 | - |
16 | - |
17 | SPARE |
18 | - |
S/B01 | - |
S/B02 | - |
S/B03 | TRLR MDL |
S/B04 | AC DC INV |
S/B05 | BATT+ |
S/B06 | - |
S/B07 | - |
S/B08 | - |
S/B09 | - |
Relays | |
RLY01 | IGN RELAY |
RLY02 | - |
