Volvo C40 Recharge 2023 Fuse Box

Volvo C40 Recharge 2023 Fuse Box Info



Passenger compartment fuse box location:

The fuse box in the passenger compartment is located behind the floor mat/panel, under the glove box.



Under the bonnet compartment fuse box location:





Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Rating Functions
1 40A Audio control device (amplifier)
2 40A Electric Module A
3 40A Electric Module B
4 40A Fan, climate control, front
5 25A Power operated tailgate*
6 20A Power seat*, left
7 20A Power seat*, right
8 - -
9 20A Door module, right rear
10 20A Door module, left rear
11 20A Door module, left front
12 15A Rear lighting
13 20A Door module, right front
14 15A Seat heating, rear*
15 5A Safety module (ASDM), Converter, rear electric motors
16 5A Calculation module
17 5A Sun sensor, Transponder for road tax
18 7.5A Steering lock
19 7.5A Control module, climate control
20 5A Interior movement detector*
21 5A Driver display
22 5A Keypad, centre console
23 5A Steering wheel module
24 5A Electronic shifting module
25 5A Centre display
26 5A Control module for online car, Control module for Connect
27 5A Antenna module (TCAM)
28 5A Relay coils
29 5A Opening the boot lid/tailgate with foot motion*
30 15A Control module, infotainment
31 10A Diagnostic port
32 5A Alcohol lock
33 15A Lowering, head restraint, left rear
34 15A Lowering, head restraint, right rear
40 30A Rear window defroster
41 40A Seatbelt pretensioner, left-hand side
42 40A Seatbelt pretensioner, right-hand side
50 - -
51 - -
52 10A Coolant pump
53 15A Steering wheel module, heated steering wheel*
54 5A Airborne Particulate Matter Sensor (APMS), Extra air heater (PTC)
55 25A Headlight washers*
56 25A Windscreen and rear window washers
57 - -
58 - -
59 - -
60 - -
61 - -
62 - -
63 5A Spare fuse
64 5A Blind Spot Information (BLIS)*
65 - -
66 - -
67 5A Control module, radar, front
68 - -
69 - -
70 5A Prepared fuse, special chassis
71 5A Collision module (SRS)
80 - -
81 5A Indicator roof console (SRS), Wake-up, electronic shifting module, 360° parking camera*
82 - -
83 7.5A Passenger compartment lighting, Dimming, interior rearview mirror, Rain and light sensors, Control panels, rear doors and cargo area, Transponder for road tax
84 5A Wireless charging plate*
85 5A Front-facing camera
86 5A Alcohol lock*
87 5A USB port
90 - -
91 - -

* Option/accessory


Under the bonnet compartment fuse box:

Fuse/Relay N° Rating Functions
1 7.5A Double USB ports, tunnel console, rear*
2 15A 12V socket, front
3 - -
4 - -
5 10A Engine Control Module (ECM)
6 15A Cooling valve block
7 5A Battery cooling valve
8 10A Control module, spoiler damper, Control module, radiator damper
9 - -
10 - -
11 - -
12 20A Headlight, right
13 20A Headlight, left
14 5A Collision module (SRS)
15 5A Accelerator pedal sensor
16 5A Powered when the car's electrical system is switched on: Engine control module, Transmission components, Electric steering servo, Central electronic module, Control module for brake system
17 5A Module, exterior sound
18 5A Alcohol lock
19 10A Lighting, rear
20 5A Internal relay coils
21 - -
22 5A Brake pedal sensor
23 5A Calculation unit
24 5A Control module, high voltage battery
25 - -
26 5A Engine Control Module (ECM)
27 15A Charging unit
28 5A Converter, front electric motor
29 20A Horn (honk)
30 5A Siren*
31 30A Windscreen wipers
32 - -
33 - -
34 - -
35 30A Brake control module
36 - -
38 30A Headlights
39 - -
40 - -
41 25A Towbar control module*
42 40A Towbar control module*
43 - -
44 - -
45 - -
46 5A Outer heat exchanger*
47 5A Control module, AC compressor, Control module, high voltage heater, Control module, electric expansion valve, Monitoring unit
48 15A Control module, high voltage battery, Converter, front and rear electric motor
49 20A Coolant pump, high voltage battery
50 20A Coolant pump, electric drive system
51 - -
52 - -
53 - -
54 - -
55 20A Headlight, left
56 20A Headlight, right

* Option/accessory
