Volvo C70 2006 Fuse Box Diagram
Fuse box location:
The fuses are located under the glovebox. The fuse box has 50 fuse positions.
Engine compartment fusebox:
The fuse box has 36 fuse positions.
Fuse Box Diagram | Layout
Engine compartment fusebox:
| Fuse N° | Rating | Functions |
| 1 | 50 A | Radiator fan |
| 2 | 80 A | Power steering |
| 3 | 60 A | Supply to passenger compartment fuse box |
| 4 | 60 A | Supply to passenger compartment fuse box |
| 5 | - | Reserve |
| 6 | - | Reserve |
| 7 | 30 A | ABS pump |
| 8 | 20 A | ABS valves |
| 9 | 30 A | Engine control module (ECM) |
| 10 | 40 A | Ventilation fan |
| 11 | 20 A | Headlamp washers, power roof, lockable storage compartment and ski hatch |
| 12 | 30 A | Supply to heated rear window |
| 13 | 30 A | Starter motor relay |
| 14 | 40 A | Trailer wiring |
| 15 | 30 A | Power roof |
| 16 | 30 A | Supply to infotainment system |
| 17 | 30 A | Windscreen wipers |
| 18 | 40 A | Supply to passenger compartment fuse box |
| 19 | - | Reserve |
| 20 | 15 A | Horn |
| 21 | 20 A | Fuel-driven additional heater, passenger compartment heater |
| 22 | 25 A | Subwoofer |
| 23 |
10 A |
Engine control module (ECM, 5-cyl. engines)/ control module for transmission (TCM) |
| 24 | - | Reserve |
| 25 | - | Reserve |
| 26 | 15 A | Ignition switch |
| 27 | 10 A | A/C compressor |
| 28 | - | Reserve |
| 29 | 15 A | Front fog lamp |
| 30 | 3 A | Reserve |
| 31 | 10 A | Reserve |
| 32 | 10 A | Injectors (5-cyl.), charge air cooler |
| 33 | 20 A | Lambda sond (5-cyl.), vacuum pump (5-cyl.) |
| 34 | 10 A | Ignition coils (petrol engines), injectors, fuel pump, pressure switch, climate control (5-cyl.) |
| 35 | 15 A | Engine sensors for valves, relay coil air conditioning, PTC element, oil trap |
| 36 | 10 A | Engine control module (ECM), accelerator pedal position sensor |
Passenger compartment:
| Fuse N° | Rating | Functions |
| 37 | - | Reserve |
| 38 | - | Reserve |
| 39 | - | Reserve |
| 40 | - | Reserve |
| 41 | - | Reserve |
| 42 | - | Reserve |
| 43 | 15 A | Telephone, sound system, RTI (option) |
| 44 | 10 A | SRS system |
| 45 | 15 A | Electrical socket, passenger compartment |
| 46 | 5 A | Passenger compartment, glovebox and courtesy lighting |
| 47 | 5 A | Interior lighting |
| 48 | 15 A | Washer |
| 49 | 10 A | SRS system |
| 50 | - | Reserve |
| 51 | 10 A | Parking assistance, relay coil for additional heater, passenger compartment |
| 52 | 5 A | Transmission control module (TCM) |
| 53 | 10 A | ABS system, power steering, Bi-Xenon lamps |
| 54 | 10 A | ECM (engine control module, 5-cyl. turbo-petrol) |
| 55 | 20 A | Keyless control module |
| 56 | 10 A | Siren control module |
| 57 | 15 A | Data link connector (DLC), brake light switch |
| 58 | 7.5 A | Main beam right, auxiliary lamps relay coil |
| 59 | 7.5 A | Main beam, left |
| 60 | 15 A | Seat heating (driver’s side) |
| 61 | 15 A | Seat heating (passenger side) |
| 62 | - | Reserve |
| 63 | 20 A | Supply, power window, right rear |
| 64 | 5 A | LED for door lock, RTI |
| 65 | 5 A | Infotainment system |
| 66 | 10 A | Infotainment control module (ICM), climate control |
| 67 | - | Reserve |
| 68 | 5 A | Cruise control |
| 69 | 5 A | Climate control, rain sensor |
| 70 | - | Reserve |
| 71 | - | Reserve |
| 72 | - | Reserve |
| 73 | 5 A | Overhead console for interior lighting (OHC), rear seatbelt reminder |
| 74 | 15 A | Fuel pump relay |
| 75 | - | Reserve |
| 76 | - | Reserve |
| 77 | 15 A | Electrical socket in cargo area, accessory electronic module (AEM) |
| 78 | - | Reserve |
| 79 | 5 A | Reversing lamp |
| 80 | - | Reserve |
| 81 | 20 A | Supply, power window, left rear |
| 82 | 25 A | Supply, power window and door, right front |
| 83 | 25 A | Supply, power window and door, left front |
| 84 | 25 A | Power passenger seat |
| 85 | 25 A | Power driver’s seat |
| 86 | 5 A | Interior lighting relay, power seats, cargo area lighting |
