Pontiac Grand Am 2002 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located on the end of the instrument panel on the driver’s side.
The instrument panel fuse box is located on the end of the instrument panel on the passenger’s side.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box (Driver’s Side):
| Fuse/Relay | Functions |
| Fuses | |
| WIPER | Windshield Wiper Motor, Washer Pump |
| TRUNK REL/RADIO AMP | Trunk Release Relay/Motor, Audio Amplifier/RFA |
| TURN LPS | Turn Signal Lamps |
| PWR MIRROR | Power Mirrors |
| AIR BAG | Air Bags |
| BFC BATT | Body Computer (BFC) |
| PCM ACC | PCM |
| DR LOCK | Door Lock Motors |
| IPC/BFC ACC | Cluster, Body Computer (BFC) |
| STOP LPS | Stop Lamps |
| HAZARD LPS | Hazard Lamps |
| IPC/ HVAC BATT | HVAC Head, Cluster, Data Link Connector |
| Circuit Breaker | |
| PWR SEAT | Power Seats |
| Relays | |
| TRUNK REL | Trunk Relay |
| DR UNLOCK | Door Unlock Relay |
| DR LOCK | Door Lock Relay |
| DRIVER DR UNLOCK | Driver’s Door Unlock Relay |
Passenger compartment fuse box (Passenger’s Side):
| Fuse/Relay | Functions |
| Fuses | |
| INST LPS | Interior Lamp Dimming |
| CRUISE SW LPS | Steering Wheel Cruise Control Switch Lamps |
| CRUISE SW | Steering Wheel Cruise Control Switches |
| HVAC BLOWER | HVAC Blower Motor |
| CRUISE | Cruise Control |
| FOG LPS | Fog Lamps |
| INT LPS | Interior Courtesy Lamps |
| RADIO BATT | Radio |
| SUNROOF | Power Sunroof |
| Circuit Breaker | |
| PWR WNDW | Power Windows |
| Relay | |
| FOG LPS | Fog Lamps |
Engine compartment fuse box:
| Fuse/Relay | Functions |
| Maxi Fuses | |
| 1 | Ignition Switch |
| 2 | Right Electrical Center-Fog Lamps, Radio, Body Function Control Module, Interior Lamps |
| 3 | Left Electrical Center-Stop Lamps, Hazard Lamps, Body Function Control Module, Cluster, Climate Control System |
| 4 | Anti-Lock Brakes |
| 5 | Ignition Switch |
| 6 | Not Used |
| 7 | Left Electrical Center-Power Seats, Power Mirrors, Door Locks, Trunk Release, Audio Amplifier, Remote Lock Control |
| 8 | Cooling Fan #1 |
| Mini Relays | |
| 9 | Rear Defog |
| 10 | Not Used |
| 11 | Not Used |
| 12 | Cooling Fan #1 |
| 13 | HVAC Blower (Climate Control) |
| 14 | Cooling Fan #2 |
| 15 | Cooling Fan |
| Micro Relays | |
| 16 | Air Conditioning Compressor |
| 17 | Not Used |
| 18 | Fuel Pump |
| 19 | Automatic Light Control |
| 20 | Automatic Light Control |
| 21 | Horn |
| 22 | Daytime Running Lamps (DRL) |
| Mini Fuses | |
| 23-32 | Spare Fuse Holder |
| 33 | Rear Defog |
| 34 | Accessory Power Outlets, Cigar Lighter |
| 35 | Not Used |
| 36 | Not Used |
| 37 | Air Conditioning Compressor, Body Function Control Module |
| 38 | Automatic Transaxle |
| 39 | Powertrain Control Module (PCM) |
| 40 | Anti-Lock Brakes (ABS), Variable Effort Steering |
| 41 | Ignition System |
| 42 | Back-Up Lamps, Automatic Transaxle Shift Lock Control System |
| 43 | Horn |
| 44 | Powertrain Control Module |
| 45 | Parking Lamps |
| 46 | Climate Control System, Air Conditioning |
| 47 | Canister Vent Valve, Exhaust Oxygen Sensors |
| 48 | Fuel Pump, Injectors |
| 49 | Generator |
| 50 | Right Headlamp |
| 51 | Left Headlamp |
| 52 | Cooling Fan #2 |
| 53 | HVAC Blower (Climate Control ) |
| 54 | Not Used |
| 55 | Cooling Fan #2 Ground |
| 56 | Fuse Puller for Mini Fuses |
| 57 | Not Used |
