Pontiac Vibe 2008 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located underneath the instrument panel on the driver’s side of the vehicle.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
Fuse/Relay Name | Functions |
TAIL | Front Parking Lamps, Taillamps, License Plate Lamps, Instrument Panel Lights, Engine Control System |
OBD | On-Board Diagnostic System |
Empty | Not Used |
P/W | Power Windows |
WIPER | Windshield Wipers |
AM2 | Charging System, Air Bag System, Starter System, Engine Control |
STOP | Stop Lamps, CHMSL, Engine Control System, Anti-lock Brakes, Cruise Control |
DOOR | Power Door Locks, Liftglass Lock |
AM1 | Cigarette Lighter, Gauge, ECU-IG, Wiper, Rear Wiper, Washer Fuses |
Empty | Not Used |
ECU-IG | Cruise Control, Anti-lock Brakes, Theft Deterrent System, Automatic Transmission Control System, Electric Cooling Fan |
RR WIPER | Rear Window Wiper, Rear Window Defogger |
A/C | Air Conditioning |
INV | Power Outlets |
P/POINT | Power Outlets |
ECU-B | Daytime Running Lamps |
CIG | Cigarette Lighter, Power Rearview Mirrors, Power Outlets, Audio System, Automatic Transaxle Control System |
GAUGE | Gauges and Meters, Back-Up Lamps, Charging System, Power Door Locks, Power Windows, Sunroof, Air Conditioning, Cruise Control |
WASHER | Windshield Washers |
M-HTR/DEF 1–UP |
Engine Control System |
HTR | Air Conditioning System |
DEF | Rear Window Defogger, M-HTR/DEF 1–UP Fuse |
POWER | Power Windows, Electric Moon Roof |
Engine compartment fuse box:
Fuse/Relay Name | Functions |
Empty | Not Used |
SPARE | Spare Fuse |
SPARE | Spare Fuse |
SPARE | Spare Fuse |
ETCS | Electronic Throttle Control System |
ABS NO. 2 | Anti-lock Brake System (Without Stability Control System) |
RDI FAN | Electric Cooling Fan |
ABS NO. 1 | Anti-lock Brake System (With Stability Control System) |
FOG | Front Fog Lamps |
EFI2 | Multiport Fuel Injection System/ Sequential Multiport Fuel Injection System, Emission Control System |
EFI3 | Multiport Fuel Injection System/ Sequential Multiport Fuel Injection System, Emission Control System |
HEAD MAIN | Right Headlamp, Left Headlamp Fuses |
ALT-S | Charging System |
EFI | Electronic Fuel Injection System |
HAZARD | Turn Signal Lamps, Emergency Flasher |
HORN | Horn |
DOME | Interior Lights, Gauges and Meters, Audio System, Remote Keyless Entry System, Navigation System (If Equipped) |
MAIN | Starter System, AM2 Fuse |
AMP | Audio System |
MAYDAY | OnStar® System |
ALT | ABS NO.1, ABS NO.2, RDI FAN, FOG, Heater, AM1, POWER, DOOR, ECU-B, TAIL, STOP, P/POINT, INV, OBD Fuses, Charging System |
HEAD RH | Right-hand Headlamp, Headlamp High Beam Indicator Lamp |
HEAD LH | Left-hand Headlamp |
M/G | M/G |
HEAD | Headlamps |
DIMMER | Headlamp Dimmer |
HORN | Horn |
FAN NO. 2 | Cooling Fan System |
FAN NO. 1 | Cooling Fan System |
EFI | Electronic Fuel Injection System |
FOG | Fog Lamps |
