Opel Grandland X 2020 Fuse Box Info
Passenger compartment fuse box location:
In left-hand drive vehicles, the fuse box is located behind a cover in the instrument panel at the left side. In right-hand drive vehicles, the fuse box is located behind a cover in the glovebox.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box (Version 1):
| Fuse/Relay N° | Functions |
| 1 | Electronic key system, Anti-theft alarm system |
| 4 | Stop-start system |
| 5 | Advanced parking assist, Camera, Transmission control module |
| 7 | Amplifier |
| 8 | Rear wiper |
| 10 | Central locking system |
| 11 | Central locking system |
| 13 | Anti-theft alarm system |
| 16 | Electrical power steering wheel |
| 18 | BTA module |
| 21 | Interior lights |
| 22 | Glovebox light |
| 23 | Blind spot alert system, Exterior mirror adjustment, Inductive charging |
| 24 | Column electrical assembly |
| 25 | Interior mirror |
| 26 | Seat belt reminder |
| 27 | Camera, Rain sensor, Automatic light control |
| 28 | USB, Infotainment |
| 31 | Airbag |
| 33 | Power outlet front |
| 36 | Infotainment |
Passenger compartment fuse box (Version 2):
| Fuse/Relay N° | Functions |
| 1 | Interior mirror, Electrical power steering wheel, Selective ride control, Radar, Diesel exhaust system |
| 3 | Trailer provisions control module |
| 4 | Horn |
| 5 | Windscreen washer |
| 6 | Windscreen washer |
| 7 | Power outlet rear |
| 10 | Doors lock, Tailgate lock |
| 11 | Doors lock, Tailgate lock |
| 12 | Stop-start system, Diagnostic connector module, Brake system |
| 13 | Infotainment, Climate control system |
| 14 | Alarm siren |
| 15 | Climate control system |
| 16 | Stop-start system, Brake system |
| 17 | Instrument cluster |
| 19 | Column electrical assembly, Steering wheel controls |
| 21 | Anti-theft alarm system |
| 22 | Camera, Rain sensor, Automatic light control |
| 23 | Seat belt reminder |
| 24 | Automatic transmission, Advanced parking assist, Panoramic view system |
| 25 | Airbag |
| 26 | Electronic Stability Control |
| 27 | Alarm |
| 28 | BTA module |
| 29 | Infotainment |
| 32 | Cigarette lighter, Power outlet front |
| 34 | Heated rear window, Heated windscreen, Inductive charging |
| 35 | Light switch, Diagnostic connector module |
| 36 | Lighting |
Engine compartment fuse box (Version 1):
| Fuse/Relay N° | Functions |
| 9 | Anti-theft alarm system |
| 10 | Stop-start system |
| 11 | Diesel exhaust system |
| 13 | Stop-start system |
| 15 | Electric power steering, Radar |
| 22 | Horn |
| 29 | Starter |
Engine compartment fuse box (Version 2):
| Fuse/Relay N° | Functions |
| 1 | Climate control |
| 2 | Steering wheel |
| 4 | Electric parking brake |
| 6 | Air vent |
| 16 | Front fog lights |
| 18 | Right high beam (Halogen), Right headlight (LED) |
| 19 | Left high beam (Halogen), Right headlight (LED) |
| 21 | Starter |
| 22 | Heated windscreen |
| 26 | Additional Heater, Heated windscreen |
