Opel/Vauxhall Antara 2010 Fuse Box Info
Fuse box location:
The fuse box is located on the lefthand side of the front passenger seat foot well, or, in right-hand drive vehicles, on the left-hand side of the driver's seat foot well.
Engine compartment fuse box:
The fuse box is located next to the coolant reservoir in the engine compartment.
Fuse Box Diagram | Layout
Instrument panel fuse box:
| N° | Fuse | Functions |
| 1 | DRVR PWR SEAT | Driver power seat |
| 2 | Spare | - |
| 3 | S/ROOF BATT | Sunroof battery |
| 4 | S/ROOF | Sunroof |
| 5 | TRLR | Trailer |
| 6 | FSCM/VENT SOL | Fuel system, vent solenoid |
| 7 | APO JACK (CONSOLE) | Power outlet (centre console) |
| 8 | CIGAR | Cigarette lighter |
| 9 | APO JACK (REAR CARGO) | Power outlet (load compartment) |
| 10 | RUN/CRNK | Run crank |
| 11 | F/DOOR LOCK | Fuel filler flap |
| 12 | HTD SEAT PWR | Seat heating |
| 13 | SPARE | - |
| 14 | BCM (TRN SIG) | Turn signals |
| 15 | CIM | Communications Integration Module |
| 16 | DR/LCK | Driver door lock |
| 17 | BCM (PRK/ TRN) | Parking lights, turn signals |
| 18 | BCM (STOP) | Brake lights |
| 19 | BCM (CTSY) | Courtesy lights |
| 20 | Spare | - |
| 21 | AMP | Amplifier |
| 22 | DRL | Daytime running lights |
| 23 | L/GATE | Tailgate |
| 24 | PASS PWR WNDW | Passenger power window |
| 25 | DRV/PWR WNDW | Driver power window |
| 26 | ACC/RAP RLY | - |
| 27 | CIGAR APO JACK RLY | - |
| 28 | RUN RLY | - |
| 29 | RUN/CRNK RLY | - |
| 30 | HEATING MAT SW | Heating mat switch |
| 31 | RUN2 | Power battery key on run |
| 32 | HVAC BLWR | Climate control, air conditioning fan |
| 33 | FSCM | Fuel system |
| 34 | ISRVM/RCM | Interior mirror, remote compass module |
| 35 | CLSTR | Instrument cluster |
| 36 | SDM (IGN 1) | Safety Diagnosis Module (Ignition) |
| 37 | SSPS | Power steering |
| 38 | OSRVM | Exterior mirrors |
| 39 | XBCM | Export Body Control Module |
| 40 | KEY CAPTURE | Key capture |
| 41 | BCM (INT LIGHT TRLR FOG) | Interior lights, trailer fog light |
| 42 | RADIO | Radio |
| 43 | IPC | Instrument panel cluster |
| 44 | STR/WHL SW | Steering wheel |
| 45 | AWD/VENT | All-wheel drive, ventilation |
| 46 | Spare | - |
| 47 | RR FOG | Heated rear window |
| 48 | PWR DIODE | Power diode |
| 49 | BCM (DIMMER) | Instrument illumination |
| 50 | BCM (VBATT) | Battery voltage |
| 51 | TRLR BATT | Trailer battery |
| 52 | Spare | - |
| 53 | XM/HVAC/ DLC | XM satellite radio, climate control, data link connection |
| 54 | SDM (BATT) | Safety Diagnosis Module (Battery) |
| 55 | PWR MODING | Power moding |
| 56 | CIM | Communications Integration Module |
| 57 | LOGISTIC MODE | Logistic mode |
Engine compartment fuse box:
| N° | Fuse | Functions |
| 1 | FAN1 RLY | - |
| 2 | FAN1 RLY | - |
| 3 | STRTR | Starter |
| 4 | BATT 3 | Instrument panel fuse box |
| 5 | FUEL/VAC | Fuel pump, vacuum pump |
| 6 | ENG SNSR | Engine sensors |
| 7 | ABS | Anti-lock Brake System |
| 8 | BCM | Body Control Module |
| 9 | FAN1 | Cooling fan |
| 10 | IGN COIL B | Ignition coil |
| 11 | IGN COIL A | Ignition coil |
| 12 | PWM FAN | Pulse width modulation fan |
| 13 | PWR/TRN RLY | - |
| 14 | STRTR RLY | - |
| 15 | FUEL/VAC PUMP RLY | - |
| 16 | ECM PWR TRN | Engine Control Module, Powertrain |
| 17 | FAN3 | Cooling fan |
| 18 | ECM | Engine Control Module |
| 19 | Spare | - |
| 20 | TCM | Transmission Control Module |
| 21 | Spare | - |
| 22 | EPB | Electrical parking brake |
| 23 | STOP LAMP | Brake lights |
| 24 | FRT WPR | Front wiper |
| 25 | STOP LAMP RLY | - |
| 26 | BATT2 | Instrument panel fuse box |
| 27 | ABS | Anti-lock Brake System |
| 28 | BATT1 | Instrument panel fuse box |
| 29 | LO BEAM RH | Low beam (righthand) |
| 30 | LO BEAM LH | Low beam (lefthand) |
| 31 | WPR CNTRL RLY | - |
| 32 | WPR SPD RLY | - |
| 33 | HTD WASH/ WPR | - |
| 34 | REAR DEFOG RLY | - |
| 35 | LOW BEAM RLY | - |
| 36 | HI BEAM RLY | - |
| 37 | FRT FOG | Front fog lights |
| 38 | HI BEAM RH | High beam (righthand) |
| 39 | HI BEAM LH | High beam (lefthand) |
| 40 | HORN | Horn |
| 41 | FRT FOG RLY | - |
| 42 | PRK LP RH | Parking light (righthand) |
| 43 | Spare | - |
| 44 | REAR WPR | Rear wiper |
| 45 | PRK LP LH | Parking light (lefthand) |
| 46 | TRLR PRL LP | Trailer parking lights |
| 47 | A/C | Climate control, air conditioning system |
| 48 | PRK LP RH | Parking light (righthand) |
| 49 | HDLP WASHER | Headlight washer |
| 50 | REAR DEFOG | Heated rear window |
| 51 | HLMP WSHR RLY | - |
