Opel/Vauxhall Meriva 2016 Fuse Box

Opel/Vauxhall Meriva 2016 Fuse Box Info



Fuse box location:

The fuse box is behind the storage compartment in the instrument panel. In right-hand drive vehicles, the fuse box is located behind a cover in the glovebox. Open the glovebox, pull cover upwards and remove.



Engine compartment fuse box:

The fuse box is in the front left of the engine compartment.



Load compartment fuse box:

The fuse box is on the left side of the load compartment behind a cover.





Fuse Box Diagram | Layout



Instrument panel fuse box:

Fuse N° Functions
1 Radio
2 Display, instrument, telephone
3 Radio
4 Ignition switch, immobiliser
5 Windscreen washer, rear screen washer
6 Central locking system, tailgate
7 Central locking system
8 Display, instrument, telephone
9 Heated steering wheel
10 Rear left door unlocking
11 Rear right door unlocking
12 Courtesy light
13 Rain sensor, interior mirror, outside mirrors
14 -



Engine compartment fuse box:

Fuse N° Functions
1 Starter
2 -
3 Fuel filter, cooling
4 Horn
5 Terminal 30
6 Engine control module, transmission control unit
7 Fog light
8 Engine cooling
9 Engine cooling
10 Vacuum pump
11 Ignition, preheating
12 Headlamp levelling
13 Air conditioning system, terminal 15
14 Transmission control unit
15 High beam right
16 High beam left
17 Engine control module
18 Engine control module, terminal 15
19 Airbag
20 Engine control module
21 Engine control module, terminal 87
22 Electrical parking brake
23 Tyre repair kit
24 Fuel pump
25 ABS
26 Heated rear window
27 ABS
28 Interior fan
29 Cigarette lighter
30 Air conditioning system
31 Front power window, left
32 Front power window, right
33 Mirror heating
34 ABS
35 Airbag



Load compartment fuse box:

Fuse N° Functions
1 Adaptive forward lighting
2 -
3 -
4 -
5 -
6 Rear power window, right
7 Adaptive forward lighting
8 Trailer module, Trailer socket
9 Left seat lumbar support
10 Left rear power window
11 Park assist
12 Electrical sunblind
13 -
14 Heated front seats
15 Trailer module
16 Right seat lumbar support
17 -
