Jeep Compass 2009 Fuse Box

Jeep Compass 2009 Fuse Box Info



Fuse box location:





Fuse Box Diagram | Layout



Engine compartment fuse box:

Fuse/Relay N° Rating Functions
1 - -
2 15A AWD/4WD ECU Feed
3 10A CHMSL Brake Switch Feed
4 10A Ignition Switch Feed
5 20A Trailer Tow
6 10A IOD Sw/Pwr Mir/ Ocm Steering Cntrl Sdar/Hands Free Phone
7 30A IOD Sense1
8 30A IOD Sense2
9 40A Power Seats
10 20A CCN Power Locks
11 15A Power Outlet
12 20A Ign Run/Acc Inverter
13 20A Pwr run/Acc Outlet RR
14 10A IOD CCN/ Interior Lighting
15 40A RAD Fan Relay Battery Feed
16 15A IGN Run/Acc Cigar Ltr/Sunroof
17 10A IOD Feed Mod-Wcm
18 40A ASD Relay Contact PWR Feed
19 20A PWR Amp 1 & Amp 2 Feed
20 15A IOD Feed Radio
21 10A IOD Feed Intrus Mod/Siren
22 10A IGN RUN Heat/AC/ Compass Sensor
23 15A ENG ASD Relay Feed 3
24 15A Power Sunroof Feed
25 10A Heated Mirror
26 15A ENG ASD Relay Feed 2
27 10A IGN RUN Only ORC Feed
28 10A IGN RUN ORC/OCM Feed
29 - Hot Car (No Fuse Required)
30 20A Heated Seats
31 10A Headlamp Washer Relay Control
32 30A ENG ASD Control Feed 1
33 10A ABS MOD/J1962 Conn/PCM
34 30A ABS Valve Feed
35 40A ABS Pump Feed
36 30A Headlamp /Washer Control / Smart Glass
37 25A 110 Inverter
