Chevrolet Orlando 2014 Fuse Box

Chevrolet Orlando 2014 Fuse Box Info



Passenger compartment fuse box location:

The fuse box is located behind the storage compartment in the instrument panel. In right-hand drive vehicles, the fuse box is located in the glove box.



Engine compartment fuse box location:





Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Functions
1 -
2 -
3 Body control module
4 Infotainment system, audio
5 Info display, face plate
6 Front power outlet
7 Power outlet
8 Body control module
9 Body control module
10 Body control module
11 Interior fan
12 -
13 Power front seat, left side
14 Dynamic light control
15 Airbag
16 Central locking system, tailgate
17 Air condition system
18 -
19 Shift lever
20 -
21 Instrument
22 Ignition, Electronic key system
23 Body control module
24 Body control module
25 Steering column lock
26 Rear power outlet



Engine compartment fuse box:

Fuse/Relay N° Functions
1 Transmission control module
2 Engine control module
3
4 Canister vent sol
5 Ignition
6 Front wipers
7 -
8 Fuel injection
9 Fuel injection, ignition system
10 Engine control module
11 Lambda sensor
12 Starter solenoid
13 Canister vent sol
14 -
15 Rear wiper
16 Ignition, Air quality sensor
17 Ignition, Airbag
18 Fuel system control module
19 -
20 Fuel pump
21 Rear power windows
22 -
23 -
24 Front power windows
25 Electronic vacuum pump
26 ABS pump
27 -
28 Heated rear window
29 -
30 ABS valve
31 Body control module
32 Body control module
33 -
34 Sunroof
35 Infotainment system, Amplifier
36 -
37 High beam, right side
38 High beam, left side
39 -
40 -
41 -
42 Cooling fan
43 -
44 -
45 Cooling fan
46 Cooling fan
47 Lambda sensor
48 Fog lights
49 -
50 -
51 Horn
52 Fuel and emission control
53 Electrochromatic mirror
54 Light switch, Light control
55 Mirror folding
56 Windscreen washer
57 Steering column lock
58 -
59 Diesel fuel heating
60 Mirror heating
61 Mirror heating
62 Air condition
63 Rear window sensor
64 Air quality sensor
65 Rear fog lamp
66 Rear washer
67 Fuel system control module
68 -
69 Battery voltage sensor
70 Rain sensor
71 -
