Audi Q5 2013 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located on the end of the instrument panel on the driver’s side of the vehicle.
The instrument panel fuse box is located on the end of the instrument panel on the passenger’s side of the vehicle.
Luggage compartment fuse box location:
The luggage compartment fuse box is located on the right side of the trunk, behind a cover.
Fuse Box Diagram | Layout
Passenger compartment fuse box (Left Side):
| Fuse/Relay N° | Rating | Functions |
| Fuse panel A (black) | ||
| 1 | 5A | Dynamic steering |
| 2 | 5A | ESC control module |
| 3 | 5A | A/C system pressure sensor, electromechanical parking brake, HomeLink, automatic dimming interior rear view mirror, air quality/outside air sensor, ESC button |
| 5 | 15A | Sound actuator/exhaust sound tuning |
| 6 | 5/7.5A | Headlight range control system/Cornering light |
| 7 | 7.5A | Headlight (cornering light) |
| 8 | 5A | Control modules (electromechanical parking brake, shock absorber, quattro Sport, trailer hitch), DCDC converter |
| 9 | 5/7.5A | Adaptive cruise control or high volzage battery (hybrid drive) |
| 11 | 5A | Side assist |
| 12 | 5A | Headlight range control, parking system |
| 13 | 5A | Airbag |
| 14 | 15A | Rear wiper |
| 15 | 10A | Auxiliary fuse (instrument panel) |
| 16 | 40A | Auxiliary fuse terminal 15 (engine area) |
| Fuse panel B (brown) | ||
| 1 | 5/10A | Electric exhaust door |
| 2 | 5A | Brake light sensor or brake pedal movement sensor (hybrid drive) |
| 3 | 25A | Fuel pump |
| 4 | 25A | Brake booster (hybrid drive) |
| 5 | 15/30A | Left seat heating with/without seat ventilation |
| 6 | 5A | ESC |
| 7 | 25A | Horn |
| 8 | 30A | Left front door (window regulator, central locking, mirror, switch, lighting) |
| 9 | 30A | Wiper motor |
| 10 | 25A | ESC |
| 11 | 30A | Left front door (window regulator, switch, lighting) |
| 12 | 5A | Rain and light sensor |
| Fuse panel C (red) | ||
| 3 | 10A | Lumbar support |
| 4 | 35A | Dynamic steering |
| 5 | 10A | Climatized cupholder |
| 6 | 35A | Windshield washer system, headlight washer system |
| 7 | 20A | Vehicle electrical system control module 1 |
| 8 | 30A | Vehicle electrical system control module 1 |
| 9 | 20A | Panorama sunroof |
| 10 | 30A | Vehicle electrical system control module 1 |
| 11 | 20A | Sun shade (panorama sunroof) |
| 12 | 5A | Anti-theft alarm warning system |
Passenger compartment fuse box (Right Side):
| Fuse/Relay N° | Rating | Functions |
| Fuse panel A (black) | ||
| 5 | 5A | Steering column switch module |
| 7 | 5A | Terminal 15 diagnostic connector |
| 8 | 5A | Gateway (Databus diagnostic interface) |
| 9 | 5A | Supplementary heater |
| Fuse panel B (brown) | ||
| 1 | 5A | CD/DVD player |
| 2 | 5A | Vi-Fi |
| 3 | 5/20A | MMI/Radio |
| 4 | 5A | Instrument cluster |
| 5 | 5A | Gateway (instrument cluster control module) |
| 6 | 5A | Ignition lock |
| 7 | 5A | Light switch |
| 8 | 40A | Climate control system blower |
| 9 | 5A | Steering column lock |
| 10 | 10A | Climate control system |
| 11 | 10A | Terminal 30 diagnostic connector |
| 12 | 5A | Steering column switch module |
Luggage compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| Fuse panel B (black) | ||
| 1 | 30A | Luggage compartment lid control module |
| 2 | 15A | Trailer control module |
| 3 | 20A | Trailer control module |
| 4 | 20A | Trailer control module |
| 5 | 5A | Electromechanical parking brake |
| 6 | 15A | Electronic damping control |
| 7 | 30A | Electromechanical parking brake |
| 8 | 30A | Rear exterior lighting |
| 9 | 35A | quattro Sport |
| 10 | 30A | Rear exterior lighting |
| 11 | 20A | Vehicle electrical system control module |
| 12 | 5A | Terminal 30 |
| Fuse panel C (brown) | ||
| 1 | 30A | Luggage compartment lid control module |
| 2 | 20A | 12-volt socket, cigarette lighter |
| 3 | 40A | DCDC converter path 1 or high voltage battery blower (hybrid drive) |
| 4 | 40A | DCDC converter path 2, DSP amplifier, radio |
| 7 | 30A | Electromechanical parking brake |
| 9 | 30A | Right front door (window regulator, central locking, mirror, switch, lighting) |
| 11 | 15A | Rear right door (window regulator, central locking, switch, lighting) |
| 12 | 5A | Cell phone prep |
| Fuse panel E (black) | ||
| 1 | 15A | Right front seat heating |
| 2 | 5A | Automatic dimming rearview mirror |
| 3 | 30A | Instrument panel terminal 30 |
| 4 | 7.5A | MMI |
| 5 | 5A | Radio |
| 6 | 5A | Rearview camera |
| 7 | 30A | Rear window heater |
| 8 | 5A | Rear Seat Entertainment |
| 12 | 15A | High voltage battery (hybrid drive) |
