Audi Q5 2012 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located on the end of the instrument panel on the driver’s side of the vehicle.
The instrument panel fuse box is located on the end of the instrument panel on the passenger’s side of the vehicle.
Luggage compartment fuse box location:
The luggage compartment fuse box is located on the right side of the trunk, behind a cover.
Fuse Box Diagram | Layout
Passenger compartment fuse box (Left Side):
| Fuse/Relay N° | Rating | Functions |
| Fuse panel A (black) | ||
| 1 | 5A | Dynamic steering |
| 3 | 5A | HomeLink |
| 5 | 5A | Climate control |
| 6 | 5A | Right headlight range adjustment |
| 7 | 5A | Left headlight range adjustment |
| 8 | 5A | Vehicle electrical system control module 1 |
| 9 | 5A | Adaptive cruise control |
| 10 | 5A | Shift gate |
| 11 | 5A | Heater washer fluid nozzles |
| 12 | 5A | Climate control |
| 13 | 5A | Cell phone prep |
| 14 | 5A | Airbag |
| 15 | 25A | Terminal 15 |
| 16 | 40A | Terminal 15 engine |
| Fuse panel B (brown) | ||
| 1 | 5A | Automatic dimming interiorrearview mirror |
| 2 | 5A | Clutch sensor |
| 3 | 25A | Fuel pump |
| 5 | 15/30A | Left seat heating with/without ventilation |
| 6 | 10A | Electronic stabilization program |
| 7 | 25A | Horn |
| 8 | 30A | Left door window regulator motor |
| 9 | 30A | Wiper motor |
| 10 | 25A | Electronic Stability Control |
| 11 | 15A | Left doors |
| 12 | 5A | Rain and light sensor |
| Fuse panel C (red) | ||
| 3 | 10A | Lumbar support |
| 4 | 35A | Dynamic steering |
| 5 | 10A | Climatized cupholder |
| 6 | 35A | Vehicle electrical system control module 1 |
| 7 | 20A | Vehicle electrical system control module 1 |
| 8 | 30A | Vehicle electrical system control module 1 |
| 9 | 20A | Panorama sunroof |
| 10 | 30A | Vehicle electrical system control module 1 |
| 11 | 20A | Panorama sunroof shade |
| 12 | 5A | Convenience electronics |
Passenger compartment fuse box (Right Side):
| Fuse/Relay N° | Rating | Functions |
| Fuse panel A (black) | ||
| 5 | 5A | Steering column switch module |
| 6 | 5A | Electronic Stability Control |
| 7 | 5A | Terminal 15 diagnostic connector |
| 8 | 5A | Gateway |
| Fuse panel B (brown) | ||
| 1 | 5A | CD/DVD player |
| 2 | 5A | Audi drive select switch module |
| 3 | 5/20A | MMI/Radio |
| 4 | 5A | Instrument cluster |
| 5 | 5A | Gateway |
| 6 | 5A | Ignition lock |
| 7 | 5A | Rotary light switch |
| 8 | 40A | Climate control system blower |
| 9 | 5A | Steering column lock |
| 10 | 10A | Climate control |
| 11 | 10A | Terminal 30 diagnostic connector |
| 12 | 5A | Steering column switch module |
Luggage compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| Fuse panel B (black) | ||
| 1 | 30A | Luggage compartment lid control module |
| 5 | 5A | Electromechanical parking brake |
| 6 | 15A | Electronic damping control |
| 7 | 30A | Electromechanical parking brake |
| 8 | 30A | Vehicle electrical system control module 2 |
| 10 | 30A | Vehicle electrical system control module 2 |
| 11 | 20A | Vehicle electrical system control module |
| 12 | 5A | Terminal 30 |
| Fuse panel C (brown) | ||
| 1 | 30A | Luggage compartment lid control module |
| 2 | 15A | Right front seat heating |
| 3 | 40A | DCDC converter path 1 |
| 4 | 40A | DCDC converter path 2 |
| 7 | 30A | Electromechanical parking brake |
| 9 | 30A | Right door control module |
| 11 | 15A | Right door control module |
| Fuse panel D (red) | ||
| 1 | 15A | Rear center console outlet |
| 2 | 15A | Center console front outlet/climatized cupholder |
| 3 | 15A | Luggage compartment outlet |
| 4 | 15A | Cigarette lighter |
| 7 | 7.5A | Parking system |
| 8 | 15A | Rear wiper |
| 9 | 5A | Electromechanical parking brake switch |
| 10 | 5A | Audi side assist |
| 12 | 5A | Terminal 15 control modules |
| Fuse panel E (black) | ||
| 3 | 30A | DSP amplifier, radio |
| 4 | 7.5A | MMI |
| 5 | 7.5A | Radio/navigation/cell phone prep |
| 6 | 5A | Rearview camera |
| 7 | 5A | cell phone prep |
