Audi e-tron 2022 Fuse Box

Audi e-tron 2022 Fuse Box Info



Passenger compartment fuse box location:

The fuse box is located on the right side below the foot board.



Engine compartment fuse box location:



Luggage compartment fuse box location:



Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Functions
  Fuse panel 1 (black)
3 Climate control system, fragrance system, ionizer
4 Head-up display
5 Audi music interface, USB port
6 DVD drive
7 Steering column lock
8 Upper/lower display
9 Instrument cluster
10 Volume control
11 Light switch, switch panels
12 Steering column electronics
15 Steering column adjustment
16 Steering column electronics
  Fuse panel 2 (black)
1 Front seat heating
2 Climate control system
3 Left headlight electronics
4 Panoramic glass roof
5 Left front door control module
6 Sockets
8 Instrument panel
9 Right headlight electronics
10 Windshield washer system/headlight washer system
12 Parking lock
  Fuse panel 3 (red)
1 Anti-theft alarm system
2 Drive system control module
3 Emergency call system
4 Selector lever
5 Horn
6 Parking brake
7 High-voltage battery, battery monitoring control module
8 Roof electronics control module
10 Airbag control module
11 Left front lumbar support
12 Diagnostic connector, light/rain sensor
14 Right front door control module
15 Climate control system compressor
16 Climate control system blower
  Fuse panel 4 (brown)
2 Right front safety belt tensioner
4 Left front safety belt tensioner
5 Air suspension/suspension control
6 Right headlight
7 Left headlight
8 Left rear door control module
9 Right rear door control module
10 Infotainment system
11 Driver assistance systems control module
12 Diagnostic interface
  Fuse panel 5 (black)
1 Seat electronics, front seat ventilation, rearview mirror, diagnostic connection
2 Vehicle electrical system control module, diagnostic interface
3 Exterior sound generator
5 Electric drive system
6 Traffic information antenna (TMC)
7 Active accelerator pedal
8 Night vision assist
9 Adaptive cruise assist
11 Driver assistance systems, intersection assistant control module
15 USB port



Engine compartment fuse box:

Fuse/Relay N° Functions
1 Charging port door
2 Climate control system compressor
4 High-voltage battery
5 High-voltage charger
6 Thermal management
7 Electric drive system
11 High-voltage charger
13 Thermal management
14 Windshield washer system control module
15 High-voltage battery water pump
16 Windshield wipers
17 Thermal management
18 Thermal management
19 Thermal management
21 Electronic Stabilization Control (ESC)



Luggage compartment fuse box:

Fuse/Relay N° Functions
  Fuse panel 1 (black)
1 Trailer hitch
3 Passenger's side rear safety belt tensioner
4 Driver's side rear safety belt tensioner
5 Trailer hitch socket
6 Left trailer hitch light
8 Rear seat heating
9 Convenience system control module, left tail light
11 Luggage compartment, charging port door central locking, convenience system control module
12 Luggage compartment lid control module
  Fuse panel 2 (black)
  Not assigned
  Fuse panel 3 (black)
1 Driver assistance systems control module
2 Audi phone box
3 Right front lumbar support
4 Side assist
5 Service disconnect switch
6 Tire pressure monitoring system
7 Auxiliary climate control
8 Exterior antenna
9 Rear climate control system control panel
10 TV tuner, data exchange and telematics control module
11 Virtual exterior mirrors, convenience access and start authorization control module
12 Garage door opener
13 Rearview camera, peripheral cameras
14 Convenience system control module, right tail light
15 Right trailer hitch light
