Audi e-tron 2020 Fuse Box

Audi e-tron 2020 Fuse Box Info



Passenger compartment fuse box location:

The fuse box is located on the right side below the foot board.



Engine compartment fuse box location:



Luggage compartment fuse box location:



Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Functions
  Fuse panel 1 (black)
3 Climate control system, fragrance system, ionizer
4 Head-up display
5 Audi music interface
6 CD/DVD drive, instrument panel
7 Steering column lock
8 Front MMI display
9 Instrument cluster
10 Volume control
11 Light switch, switch panels
12 Steering column electronics
15 Steering column adjustment
16 Steering column electronics
  Fuse panel 2 (black)
1 Front seat heating
2 Climate control system
3 Left headlight electronics
4 Panoramic glass roof
5 Left front door control module
6 Sockets
8 Instrument panel
9 Right headlight electronics
10 Windshield washer system/headlight washer system
12 Parking lock
  Fuse panel 3 (red)
1 Anti-theft alarm system
2 Drive system control module
3 Emergency call system
4 Selector lever
5 Horn
6 Parking brake
7 High-voltage battery, battery monitoring control module
8 Interior headliner lights
10 Airbag control module
11 Left front lumbar support
12 Diagnostic connector, light/rain sensor
14 Right front door control module
15 Climate control system, body electronics
16 Climate control system blower
  Fuse panel 4 (brown)
2 Right front safety belt tensioner
4 Left front safety belt tensioner
5 Air suspension
6 Right headlight
7 Left headlight
8 Left rear door control module
9 Right rear door control module
10 MMI Infotainment system control module
11 Driver assist systems control module
12 Gateway control module (diagnosis)
  Fuse panel 5 (black)
1 Front seat ventilation, rearview mirror, diagnostic port
2 Sockets
3 Exterior sound/interior sound
7 Active accelerator pedal
8 Night vision assist
9 Adaptive cruise assist
11 Intersection assistant, driver assist systems
16 Rear seat entertainment



Engine compartment fuse box:

Fuse/Relay N° Functions
1 Charging port door
2 A/C compressor
5 Charging system
7 Electric motor
10 Voltage converter
11 Charging system
13 Thermal management
14 Windshield wiper control module
15 High-voltage battery water pump
16 Windshield wipers
17 Thermal management
18 Thermal management
19 Thermal management
22 Electronic Stabilization Control (ESC), thermal management



Luggage compartment fuse box:

Fuse/Relay N° Functions
  Fuse panel 1 (black)
1 Trailer hitch
3 Passenger's side rear safety belt tensioner
4 Driver's side rear safety belt tensioner
5 Trailer hitch socket
6 Left trailer hitch light
8 Rear seat heating
9 Tail lights
11 Central locking, rear blind
12 Luggage compartment lid
  Fuse panel 2 (black)
  Not assigned
  Fuse panel 3 (black)
1 Driver assist systems control module
2 Phone, roof antenna
3 Right front lumbar support
4 Side assist
5 Service Disconnect
6 Tire pressure monitoring system
7 Interior climate control
9 Rear climate control system control panel
11 Vehicle opening/start (NFC)
12 Garage door opener
13 Rearview camera, peripheral cameras
14 Tail lights
15 Right trailer hitch light
