GAC Empow 2023 Fuse Box

GAC Empow 2023 Fuse Box Info



Passenger compartment fuse box location:

The instrument panel fuse box is located to the left of the steering wheel, under the cover.



Engine compartment fuse box location:







Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Rating Functions
IF01 20A Front 12V power outlet
IF02 7.5A BCM
IF03 7.5A ACU/DSM ECU *
IF04 7.5A USB charging port */Mobile phone WCM */DVR USB port *
IF05 - -
IF06 - -
IF07 - -
IF08 7.5A T-BOX ECU*
IF09 7.5A HVAC control unit/Mobile phone WCM*/RF receiver module/RLS*/Smart Bluetooth module*
IF10 10A AV display (10.25-inch)/HCP/IAL*
IF11 7.5A OBU/GSM/SVM ECU*/Left rear BSD ECU*/Right rear BSD ECU*/DSM ECU*
IF12 - -
IF13 7.5A Electronic anti-dazzling interior rearview mirror*/ defogger relay (ER07)
IF14 7.5A BCM
IF15 - -
IF16 - -
IF17 10A SRS ECU
IF18 7.5A ECM/7WDCT TCU/Electronic P gear actuator
IF19 7.5A GWM/BCM
IF20 - -
IF21 7.5A Brake switch/ESPI
IF22 7.5A EPS ECU/GSM
IF23 7.5A On-board ETC unit/Power sunroof ECU*/Left front seat connector A (HVSM power supply)*/HCP/HVAC control unit
IF24 - -
IF25 7.5A Plasma generator*/ALS switch/front combination lamp (ALS motor power supply)
IF26 7.5A LDW */MRR module */instrument cluster */ACU/T-BOX control unit */RPA ECU/AVM ECU *
IF27 - -
IF28 - -
IF29 - -
IF30 - -
IF31 20A BCM (door lock power supply)
IF32 20A BCM
IF33 20A BCM (wiper power supply)
IF34 - -
IF35 7.5A GWM
IF36 15A BCM (turn signal lamp power supply)
IF37 - -
IF38 - -
IF39 7.5A Instrument cluster*/instrument cluster display (10.25-inch)
IF40 7.5A Fuel filler cap lock motor/fuel filler cap lock relay (IR05)
IF41 7.5A OBD DLC
IF42 - -
IF43 Dark current
switch
T-BOX ECU */HVAC control unit/mobile phone WCM */RF receiver module/RLS */smart Bluetooth module */AV system display (10.25-inch)/HCP/IAL */on-board ETC unit/GSM/AVM ECU */left rear BSD
ECU */right rear BSD ECU */driver status monitoring ECU *
IF44 - -
IF45 30A Right front door control module
IF46 30A Left front door control module
IF47 20A BCM (main lighting power supply 2)
IF48 20A BCM (main lighting power supply 1)
IF49 10A Left front seat connector A (HVSM power supply) *
IF50 15A IG2 power supply
IF51 20A Left front seat connector A (seat controller power supply) *
IF52 20A Right front seat connector A (seat adjusting switch power supply) *
IF53 15A BCM (windshield washer motor power supply)
IF54 20A ACU
IF55 20A Power sunroof ECU*
IF56 - -
IF57 - -
IF58 - -
IR01 - ACC relay
IR02 - -
IR03 - -
IR04 - IG1 relay
IR05 - Fuel filler cap lock relay
IR06 - -
IR07 - IG2 relay

* if equipped



Engine compartment fuse box:

Fuse/Relay N° Rating Functions
EF01 - -
EF02 - -
EF03 - -
EF04 7.5A ECM
EF05 - -
EF06 - -
EF07 15A Exterior rearview mirror heater
EF08 - -
EF09 - -
EF10 30A 7WDCT TCU
EF11 30A 7WDCT TCU
EF12 15A Horn relay (ER03)/horn
EF13 30A 7WDCT TCU
EF14 7.5A MRR module */LDW ECU *
EF15 - -
EF16 20A Fuel pump
EF17 20A Wiper/wiper speed control relay (ER11)/wiper relay (ER12)
EF18 7.5A Brake switch
EF19 7.5A Main relay (ER17)/ECM
EF20 - -
EF21 - -
EF22 60A To instrument panel PDU
EF23 40A ESPI
EF24 30A IG1 On
EF25 30A Starter
EF26 40A ACC power supply
EF27 40A Blower
EF28 40A Rear windshield defogger heater +/exterior rearview mirror heater*
EF29 - -
EF30 50A Cooling fan (low gear)
EF31 - -
EF32 60A To instrument panel PDU
EF33 60A Cooling fan (high gear)
EF34 - -
EF35 10A Low speed fan relay (ER06)/high speed fan relay (ER09)/ Fuel pump relay (ER14)/water pump relay (ER02)
EF36 15A Ignition coil 1/ignition coil 2/ignition coil 3/ignition coil 4
EF37 15A ECM/Starter relay 1(ER15)/Starter relay 2(ER16)
EF38 10A Upstream oxygen sensor/Downstream oxygen sensor/Compressor relay (ER04)
EF39 10A PCV heater relay (ER10)/PCV heater/Canister vent valve/ Relief valve/Canister solenoid valve/Oil pump solenoid valve/Oil control valve (intake end)/Oil control valve (exhaust end)
EF40 10A Left EAV valve */Right EAV valve *
EF41 - -
EF42 - -
EF43 10A Electric water pump
EF44 - -
EF45 7.5A A/C compressor
EF46 20A Left front seat connector A (HVSM and seat controller power supply) *
EF47 - -
EF48 40A ESPI
EF49 30A Electronic P gear actuator
EF50 - -
ER01 - -
ER02 - Water pump relay
ER03 - Horn relay
ER04 - Compressor relay
ER05 - Blower relay
ER06 - Low speed fan relay
ER07 - Defogger relay
ER08 - -
ER09 - High speed fan relay
ER10 - PCV heater relay
ER11 - Wiper speed control relay
ER12 - Wiper relay
ER13 - -
ER14 - Fuel pump relay
ER15 - Starter relay 1
ER16 - Starter relay 2
ER17 - Main relay

* if equipped



Engine compartment fuse box (On battery):

Fuse/Relay N° Rating Functions
PF01 300A Starter/Engine compartment PDU/Alternator
PF02 7.5A EBS
PF03 80A EPS ECU
