Can-Am Spyder RT Series 2022 Fuse Box Info
Fuse box location:
Fuses are located in the front storage compartment.
Fuse Box Diagram | Layout
Left fuse box:
| Fuse/Relay N° | Rating | Functions |
| Fuses | ||
| 1 | 15A | Cluster / DLC |
| 2 | 10A | Wake-up ECM / VCM / MSR and DESS / SAS / YAS / PRS |
| 3 | 10A | Alternator |
| 4 | 20A | WPM |
| 5 | 5A | ECM |
| 6 | 15A | Injectors / Coils |
| 7 | 10A | Wake-up TCM, DPS / Cluster, Fuel gauge and Coolant temperature gauge |
| 8 | 15A | H02S / CAPS/ Fuel pump / EVAP / CSV, PSR |
| JCase Fuses | ||
| 1 | 40A | VCM pump |
| 2 | 25A | VCM valves |
| 3 | 40A | DPS |
| 4 | 40A | Main control (F1, F2, R4, R5) |
| 5 | - | Not used |
Right fuse box:
| Fuse/Relay N° | Rating | Functions |
| Fuses | ||
| 1 | 15A | Days lights / Parking lamps / Plate lights |
| 2 | 10A | Brake lights / Hazard |
| 3 | 15A | Amplifier |
| 4 | 10A | Trailer module |
| 5 | 25A | Horn, Load shedding |
| 6 | 5A | DC plugs VKEY |
| 7 | 5A | DC Plugs VBAT |
| 8 | - | Not used |
| JCase Fuses | ||
| 1 | 30A | Cooling fan |
| 2 | 40A | Accessories |
| 3 | 20A | TCM solenoids |
| 4 | 30A | LO headlamps |
| 5 | 20A | HI headlamps |
Alternator Circuit Fuse (The fuse holder is located to the LH of the battery):
| Fuse/Relay N° | Rating | Functions |
| 80A | Alternator |
