Can-Am Spyder RT Series 2013 Fuse Box Info
Fuse box location:
Fuses are located in the front storage compartment.
Fuse Box Diagram | Layout
Left fuse box:
| Fuse/Relay N° | Rating | Functions |
| Fuses | ||
| 1 | 15A | Cluster / DLC / DESS |
| 2 | 10A | Wake-up ECM / VCM / MSR and DESS / SAS / YAS / PRS |
| 3 | - | Not used |
| 4 | 20A | WPM / PBM |
| 5 | 5A | ECM |
| 6 | 15A | Injectors / Coils |
| 7 | 10A | Wake-up TCM, DPS / Cluster |
| 8 | 15A | H02S / CAPS / Fuel Pump / EVAP / CSV |
| JCase Fuses | ||
| 1 | 30A | Cooling fan(s) |
| 2 | 40A | Main control |
| 3 | 40A | DPS |
| 4 | 25A | MVCM valves |
| 5 | 40A | VCM pump |
Right fuse box:
| Fuse/Relay N° | Rating | Functions |
| Fuses | ||
| 1 | 15A | Days lights / Parking lamps / Plate lights |
| 2 | 10A | Brake lights / Hazard |
| 3 | 15A | Radio |
| 4 | 10A | Trailer |
| 5 | 20A | Load shedding |
| 6 | 10A | DC plugs VKEY |
| 7 | 10A | Plugs VBAT |
| 8 | - | Not used |
| JCase Fuses | ||
| 1 | - | Not used |
| 2 | 40A | Accessories |
| 3 | 20A | TCM solenoids |
| 4 | 30A | LO headlamps |
| 5 | 20A | HI headlamps |
