Genesis G70 2022 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located at the left side of the steering column at the bottom of the instrument panel.
Engine compartment fuse box location:
Luggage compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| MULTI MEDIA1 | 20A | [W/O ISG] Fuse - F11, F12 [With ISG] Low DC-DC Converter (Audio) |
| AIR BAG1 | 15A | SRS Control Module |
| ROOM LAMP | 10A | Overhead Console Lamp, Center Room Lamp, Room Lamp Vanity Lamp Switch LH/RH, Luggage Lamp LH/RH Glove Box Lamp, Driver/Passenger Foot Lamp |
| STOP LAMP | 10A | IBU, Stop Lamp Switch |
| CLUSTER | 10A | Instrument Cluster, Head-Up Display |
| E-SHIFTER2 | 10A | Electronic ATM Shift Lever |
| IBU3 | 10A | IBU |
| MULTI MEDIA3 | 10A | [With ISG] Instrument Cluster, Head-Up Display, A/C Switch Front Wireless Charger, Around View Monitor [W/O ISG] Around View Monotor |
| MULTI MEDIA2 | 15A | Audio |
| MEMORY1 | 10A | A/C Control Module, A/C Switch, Security Indicator Head-Up Display, Power Tail Gate Unit, Power Trunk Module [W/O ISG] Instrument Cluster |
| IBU4 | 10A | IBU |
| E-SHIFTER1 | 10A | Electronic ATM Shift Lever |
| AIR BAG IND. | 10A | Instrument Cluster, Overhead Console Lamp |
| IBU1 | 15A | IBU, Driver/Passenger Smart Key Outside Handle, Driver/Passenger Power Outside Mirror |
| DRIVER DR MODULE |
10A | Driver Door Module, Driver/Passenger Power Outside Mirror |
| E-CALL | 10A | Emergency Call Module |
| MODULE2 | 10A | IBU |
| MODULE3 | 10A | Driver Door Module, Stop Lamp Switch |
| DOOR LOCK | 20A | Door Lock Relay, Door Unlock Relay, Dead Lock Relay |
| SEAT HEATER | 25A | Front Air Ventilation Seat Control Module Front Seat Warmer Control Module |
| TRUNK | 10A | Trunk Lid Relay, Fuel Lid Relay, Crash Pad Switch |
| IBU2 | 10A | IBU, Rain Sensor |
| AIR BAG2 | 15A | SRS Control Module |
| POWER OUTLET1 | 20A | Front Power Outlet |
| MODULE8 | 10A | Cooling Fan Controller (BLDC Motor) |
| MODULE7 | 10A | Dosing Control Module, AWD ECM, Active Air Flap LH, ECS Unit, Smart Cruise Control Module, Console Switch, Crash Pad Switch, IBU, Console Switch, Multi-Function Camera Unit, Front Wireless Charger, Steering Tilt & Telescopic Module, Around View Monitor, Electronic Control Engine Mounting Module, Steering Angle Sensor |
| POWER HANDLE | 15A | Steering Tilt & Telescopic Module |
| MODULE9 | 10A | Driver Air Lumbar Control Unit |
| MODULE1 | 10A | Data Link Connector, Console Switch, Hazard Switch, Electronic Control Engine Mounting Module |
| CHARGER | 10A | Front/Rear USB Charger, Front Tray USB Charger |
| MODULE5 | 10A | A/C Control Module, A/C Switch, A/V & Navigation Head Unit, Low DC-DC Converter (Audio/AMP), Electro Chromic Mirror, AMP, Emergency Module, Driver IMS Control Module, Front Air Ventilation Seat Control Module, Data Link Connector, Front/Rear Seat Warmer Control Module, IFS Module |
| SUNROOF | 20A | Sunroof Control Unit (Glass) |
| PASSENGER P/ WINDOW |
25A | Passenger Safety Power Window Module, Rear Power Window Switch RH, Rear Safety Power Window Module RH |
| POWER OUTLET2 |
20A | [5DR] Rear Power Outlet |
| WASHER | 15A | Multifunction Switch |
| MDPS | 10A | MDPS Unit |
| DRIVER P/SEAT |
30A | Driver IMS Control Module, Driver Seat Manual Switch |
| PASSENGER P/SEAT |
30A | Passenger Seat Manual Switch, Passenger Walk In Relay Module |
| DRIVER P/WINDOW |
25A | Driver Safety Power Window Module, Rear Safety Power Window Module LH, Rear Power Window Switch LH |
| MODULE6 | 10A | Around View Monitor, IBU, Emergency Call Module, AMP, Electronic ATM Shift Lever, Overhead Console Lamp, A/V & Navigation Head Unit, Low DC-DC Converter (Audio/AMP) |
| A/CON | 10A | A/C Control Module, A/C Switch, PM Sensor (A/C), E/R Junction Block (RLY.6), Diesel Junction Block (RLY.3/4) |
| MODULE4 | 10A | Head Lamp LH/RH, Auto Head Lamp Leveling Device Module |
Engine compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| ALT |
175A 225A |
Alternator, Fuse - F2, Multi Fuse 1 - F4, F6, F7, F8, F9, F10, F11, F12, F13 |
|
C/FAN3 GLOW |
125A |
[G6DP - BLDC Motor] Cooling Fan Controller [D4HB] Glow Relay Unit |
| START | 30A | RLY. 7 (Start Relay) |
| C/FAN1 | 80A | [BLDC Motor] Cooling Fan Controller |
| B+3 | 50A | ICU Junction Block (Fuse - F5, Leak Current Autocut Device Fuse - F2, F4, F13, F14, F21, F22) |
| B+2 | 50A | ICU Junction Block (Fuse - F27, F35, F43, F51, F52) |
| B+1 | 50A | ICU Junction Block (Fuse - F28, F29, F37, F45, F53) |
| EOP | 50A | [With ISG] Electric Oil Pump Module |
| ESP1 | 40A | ESP Control Module |
| ESP2 | 40A | ESP Control Module |
| BLOWER | 40A | RLY. 6 (Blower Relay) |
| IG2 | 30A | PCB Block (IG2 Relay) |
| MDPS | 100A | MDPS Unit |
| B+4 | 60A | PCB Block (Engine Control Relay, Fuse - F4, F5, F13, F22) |
| C/FAN2 | 60A | [DC Motor] RLY. 9 (Cooling Fan Relay) |
| E-CVVT1 | 40A | [G4KL] RLY. 8 (E-CVVT Relay) |
| TRAILER | 40A | Trailer Connector |
| FUEL HEATER | 40A | Diesel Junction Block (RLY.1 (Fuel Filter Heater Relay)) |
| PTC HEATER1 | 30A | Diesel Junction Block (RLY.2 (PTC Heater #1 Relay)) |
| PTC HEATER2 | 30A | Diesel Junction Block (RLY.3 (PTC Heater #2 Relay)) |
| PTC HEATER3 | 30A | Diesel Junction Block (RLY.4 (PTC Heater #3 Relay)) |
| VACUUM PUMP | 20A | [G4KL/G6DP] RLY. 1 (Vacuum Pump Relay) |
| AWD | 20A | AWD ECM |
| A/CON | 10A | A/C Control Module |
| E-CVVT3 | 20A | [G4KL] ECM |
| E-CVVT2 | 20A | [G4KL] ECM |
| ESC3 | 10A | ESP Control Module |
| ECU3 | 10A | ECM |
| ECU2 | 15A | ECM |
| HORN | 20A | Horn Relay |
| WIPER1 | 30A | Wiper Power Relay |
| TCU2 | 15A | P/N Relay, TCM |
| SENSOR4 | 10A | Electronic Oil Pump Module, Brake Vacuum Switch, E/R Junction Block (RLY.1 (Brake Vacuum Relay)) |
| TCU1 | 20A | TCM |
| WIPER2 | 10A | IBU, ECM |
| SENSOR1 | 15A | Rear Sub Junction Block (Fuel Pump Relay), [D4HB] Rail Pressure Regulating Valve, DieseL Junction Block (RLY.1 (Fuel Filter Heater Relay)) |
| SENSOR5 | 20A | [G4KL] Ignition Coil #1/#2/#3/#4 [G6DP] Ignition Coil #1/#2/#3/#4/#5/#6 [D4HB] Electronic Water Pump |
| MODULE | 10A | Active Air Flap LH |
| ACTIVE HOOD | 10A | Active Hood Lift Control Module |
| SENSOR1 | 10A | [D4HB] Glow Relay Unit, Fuel Heater & Water Separator Sensor |
| ECU1 | 20A | ECM |
| SENSOR3 | 15A | [G4KL] Oxygen Sensor (Up/Down) [G6DP] Oxygen Sensor #1/#2/#3/#4 [D4HB] Lambda Sensor #1/#2, Electronic VGT Actuator, Fuel Metering Unit, EGR Cooing Bypass Solenoid Vlave, PTC Heater, Mid Nox Sensor, PM Sensor, Rear Nox Sensor |
| SENSOR2 | 10A | E/R Junction Block (RLY. 9 - Cooling Fan Relay), [G4KL] Electronic Thermostat, Oil Control Valve, Purge Control Solenoid Valve, Recirculation Control Solenoid Valve [G6DP] Electronic Thermostat, Oil Pressure Solenoid Valve, Oil Control Valve #1/#2/#3/#4 (Intake/Exhaust), Recirculation Control Solenoid Valve, Purge Control Solenoid Valve, Variable Exhaust Flap Actuator LH/RH [D4HB] Oil Pump Solenoid Valve, Air Flow Sensor, Crankshaft Position Sensor, Front Nox Sensor, Oil Level Sensor, Stop Lamp Switch |
| B/ALARM | 10A | E/R Junction Block (RLY. 2 - Burglar Alarm Horn Relay) |
Luggage compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| DCU2 | 15A | Dosing Control Module |
| DCU3 | 15A | Dosing Control Module |
| REAR WIPER | 15A | Wipre RR Relay, Rear Wiper Motor |
| ECS | 15A | ECS Unit |
| POWER TRUNK | 30A | Power Trunk Module, Power Tailgate Unit |
| DCU1 | 15A | Dosing Control Module |
| FUEL PUMP | 20A | Fuel Pump Relay |
| HEAT MIRROR | 10A | A/C Switch, Driver/Passenger Power Outside Mirror |
| AMP2 | 25A | AMP |
| REAR S/HEAT | 20A | Rear Seat Warmer Control Module |
| AMP1 | 30A | [W/O ISG] Fuse - F9 [With ISG] Low DC-DC Converter (AMP) |
| IG1 | 15A | PCB Block (IG1 Relay) |
| ACC | 30A | ICU Junction Block (Fuse - F32, F40, F54) |
| B+1 | 40A | ICU Junction Block (IPS5, IPS6, IPS7, IPS8, IPS9, IPS10, Fuse - F20, 30F) |
| B+2 | 40A | ICU Junction Block (IPS1, IPS2, Fuse - F15, F39) |
| REAR HEATED | 30A | Rear Heated Relay |
Battery box fuse panel:
| Fuse/Relay Name | Rating | Functions |
| B+1 | 100A | Rear Sub Junction Block (ACC Relay, Fuse - F7, F12, F13, F16, F17) |
| B+2 | 100A | Rear Sub Junction Block (DCU Relay, Fuse - F3, F5, F4, F11, F15) |
| START | 40A | E/R Junction Block (Fuse - F3), PCB Block (Fuse - F3, F9) |
| AMS | 10A | Battery Sensor |
