Holden Spark 2019 Fuse Box

Holden Spark 2019 Fuse Box Info



Passenger compartment fuse box location:

The interior fuse box is located on the underside of the driver side of the instrument panel.



Engine compartment fuse box location:





Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Functions
Fuses
1 Onstar
2 HVAC module
3 Instrument panel cluster
4 Continuously Variable transmission control module
5 Radio
6 Body control module 1 (CVT stop & start)
7 Side blind spot alert/Rear parking assist
8 Data link connection
9 Electric steering column lock
10 Sensing and Diagnostic module
11 DC-DC converter
12 Virtual Key pass System Module
13 Electronic toll collection system
14 Linear power module (NON KOR)
15 Passive entry & passive start
16 Discrete logic ignition switch (Non CVT stop & start)
17 Side blind spot alert/Rear parking assist
18 Instrument panel cluster
19 Reflected LED Alert Display
20 Headlamp levelling switch
21 Front power window
22 Rear power window
23 -
24 Automated manual transmission module
25 Auxiliary power outlet
26 Sunroof
27 Central Gate Module
28 Body control module 8
29 Body control module 7
30 Body control module 6
31 Body control module 5
32 Body control module 4
33 Body control module 3
34 Body control module 2 (Non CVT stop & start)
35 Body control module 1 (Non CVT stop & start)
36 Discrete logic ignition switch (CVT stop & start)
37 Steering wheel controls backlighting
38 Linear power module (KOR Only)
39 Logistic/DC-DC converter
40 Driver express power window
41 Blower motor
42 Front heated seat
43 HVAC module
44 Heated steering wheel
45 Body control module 2 (CVT stop & start)
Relays
1 Logistic relay
2 ACC/RAP relay
3 IRAP relay
4 RUN relay





Engine compartment fuse box:

Fuse/Relay N° Functions
Fuses
1 Tailgate latch
2 Transmission Output Speed Sensor
3 Rear demist
4 Outside rear view mirror heater
5 Sunroof
6 CVT control module
7 Mass air flow sensor
8 -
9 ABS valve
10 Regulated voltage control
11 Rear view camera
12 -
13 -
14 ECM/TCM
15 FICM / Starter
16 Fuel pump motor
17 ECM 1
18 ECM 2
19 Injector, Ignition
20 A/C system
21 Intelligent battery sensor
22 Electric steering column lock
23 Cooling fan low
24 Virtual Key pass System Sensor
25 Outside rear view mirror switch
26 ECM/Automated manual transmission module
27 Canister vent solenoid
28 -
29 Auxiliary occupant sensing
30 Headlamp levelling motor
31 Horn
32 Front fog lamp
33 High beam left
34 High beam right
35 Air Quality Ioniser
36 Rear wiper motor
37 Cornering lamp left
38 Washer pump motor
39 Cornering lamp right
40 -
41 Virtual Key pass System Sensor
42 Starter 2
43 In-panel bussed electric centre
44 Automated manual transmission/DC-DC converter
45 Starter 1
46 Antilock brake system pump
47 Cooling fan HI
48 Front wiper motor
49 In-panel bussed electric centre accessory/RAP power
Relays
1 Rear demist relay
2 TCM relay
3 Fuel pump motor relay
4 STRTR SOL2 relay
5 Air conditioning clutch relay
6 -
7 Fan lo relay
8 RUN/CRNK relay
9 PWR/TRN relay
10 STRTR SOL1 relay
11 Fan HI relay
12 Front fog lamp relay
