Volvo XC70 2015 Fuse Box Info
Passenger compartment fuse box location:
The fuse boxes A and B in the passenger compartment are located under the glove box.
Engine compartment fuse box location:
Luggage compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box (Fuse box A):
| Fuse/Relay N° | Rating | Functions |
| 1 | 40A | Circuit breaker for the infotainment system and for fuses 16-20 |
| 2 | - | - |
| 3 | - | - |
| 4 | 10A | Heated steering wheel* |
| 5 | - | - |
| 6 | - | - |
| 7 | 15A | 12-volt socket (cargo area) |
| 8 | 20A | Controls in driver's door |
| 9 | 20A | Controls in front passenger's door |
| 10 | 20A | Controls in right rear passenger's door |
| 11 | 20A | Controls in left rear passenger's door |
| 12 | 20A | Keyless drive* |
| 13 | 20A | Power driver's seat* |
| 14 | 20A | Power front passenger's seat* |
| 15 | - | - |
| 16 | 5A | Infotainment system control module |
| 17 | 10A | Infotainment system: amplifier, SiriusXM™ satellite radio* |
| 18 | 15A | Infotainment system |
| 19 | 5A | Bluetooth hands-free system |
| 20 | 7.5A | Rear Seat Entertainment system (RSE)* |
| 21 | 5A |
Power moonroof* Courtesy lighting, climate system sensor |
| 22 | 15A | 12-volt sockets in tunnel console |
| 23 | 15A | Heated rear seat* (passenger's side) |
| 24 | 15A | Heated rear seat* (driver's side) |
| 25 | - | - |
| 26 | 15A | Heated front passenger's seat* |
| 27 | 15A | Heated driver's seat* |
| 28 | 5A | Park assist*, trailer hitch control module*, park assist camera* |
| 29 | 5A | All Wheel Drive* control module |
| 30 | 5A | Active chassis system* |
* Option/accessory
Passenger compartment fuse box (Fuse box B):
| Fuse/Relay N° | Rating | Functions |
| 1 | 15A | Tailgate wiper |
| 2 | - | - |
| 3 | 7.5A | Front courtesy lighting, driver's door power window controls, power seat(s)*, HomeLInk® Wireless Control System* |
| 4 | 5A | Instrument panel |
| 5 | 10A | Adaptive cruise control/ collision warning* |
| 6 | 7.5A | Courtesy lighting, rain sensor* |
| 7 | 7.5A | Steering wheel module |
| 8 | 10A | Cental locking: fuel filler door |
| 9 | 15A | Tailgate window washer |
| 10 | 15A | Windshield washers |
| 11 | 10A | Tailgate unlock |
| 12 | 10A | Electrical folding rear seat outboard head restraints* |
| 13 | 20A | Fuel pump |
| 14 | 5A | Climate system control panel |
| 15 | - | - |
| 16 | 5A | Alarm, On-board diagnostic system |
| 17 | - | - |
| 18 | 10A | Airbag system, Occupant weight system |
| 19 | 5A | Collision warning system* |
| 20 | 7.5A | Accelerator pedal sensor, auto-dim mirror function, heated rear seats* |
| 21 | - | - |
| 22 | 5A | Brake lights |
| 23 | 20A | Power moonroof* |
| 24 | 5A | Immobilizer |
* Option/accessory
Engine compartment fuse box (Fuse box A):
| Fuse/Relay N° | Rating | Functions |
| 1 | 50A | Circuit breaker: central electrical module under the glove compartmentA |
| 2 | 50A | Circuit breaker: central electrical module under the glove compartment |
| 3 | 60A | Circuit breaker: central electrical module in the cargo compartmentA |
| 4 | 60A | Circuit breaker: central electrical module under the glove compartmentA |
| 5 | 50A | Circuit breaker: central electrical module under the glove compartmentA |
| 6 | - | - |
| 7 | - | - |
| 8 | 40A | Headed windshield*, driver's side |
| 9 | 30A | Windshield wipers |
| 10 | - | - |
| 11 | 40A | Climate system blowerA |
| 12 | 40A | Headed windshield*, passenger's side |
| 13 | 40A | ABS pump |
| 14 | 20A | ABS valves |
| 15 | 20A | Headlight washers |
| 16 | 10A | Active Bending Lights. Headlight leveling* |
| 17 | 20A | Central electrical module (under the glove compartment) |
| 18 | 5A | ABS |
| 19 | 5A | Adjustable steering force* |
| 20 | 10A | Engine Control Module (ECM), transmission, SRS |
| 21 | 10A | Heated washer nozzles* |
| 22 | - | - |
| 23 | 5A | Lighting panel |
| 24 | - | - |
| 25 | - | - |
| 26 | - | - |
| 27 | 5A | Relay coils |
| 28 | 20A | Auxiliary lights* |
| 29 | 15A | Horn |
| 30 | 10A | Relay coils, Engine Control Module (ECM) |
| 31 | 15A | Control module - automatic transmission |
| 32 | 15A | A/C compressor (not 4-cyl. engines) |
| 33 | 5A | Relay-coils A/C, relay coils in engine compartment cold zone for Start/Stop |
| 34 | 30A | Starter motor relayA |
| 35 | 20A | Engine control module (4-cyl. engines), Ignition coils (5-/6-cyl. engines), condenser (6-cyl. engines) |
| 36 |
20A 10A |
Engine Control Module (4-cyl. engines) Engine Control Module (5-cyl. & 6-cyl. engines) |
| 37 |
10A 15A |
4-cyl. engines: mass air meter, thermostat, EVAP valve 5-/6-cyl. engines: Injection system, mass air meter (6-cyl. engines only), engine control module |
| 38 |
10A 15A |
A/C compressor (5-/6- cyl. engines), engine valves, engine control module (6-cyl. engines), solenoids (6- cyl. non-turbo only), mass air meter (6-cyl. only) Engine valves/oil pump/center heated oxygen sensor (4-cyl. engines) |
| 39 | 15A | Front/rear heated oxygen sensors (4-cyl. engines), EVAP valve (5-/6-cyl. engines), heated oxygen sensors (5-/6-cyl. engines) |
| 40 |
10A 15A |
Oil pump (automatic transmission)/crank-case ventilation heater (5-cyl. engines) Ignition coils |
| 41 |
5A 15A |
Fuel leakage detection (5-/6-cyl. engines), control module for radiator shutter (5-cyl. engines) Fuel leakage detection, A/C relay (4-cyl. engines) |
| 42 | 50A | Coolant pump (4-cyl. engines) |
| 43 |
60A (4/5- cyl. engines) 80A (6-cyl. engines) |
Cooling fan
|
| 44 | 100A | Power steering |
* Option/accessory
A This position is not used on vehicles with the optional Start/Stop function
Engine compartment fuse box B (Engine compartment cold zone (Start/Stop only)):
| Fuse/Relay N° | Rating | Functions |
| A1 | 175A | Circuit breaker: central electrical module in the engine compartment |
| A2 | 175A | Circuit breaker: fuseboxes under the glove compartment, central electrical module in the cargo area |
| 1 | - | - |
| 2 | 50A | Circuit breaker: fusebox B under the glove compartment |
| 3 | 60A | Circuit breaker: fusebox A under the glove compartment |
| 4 | 60A | Circuit breaker: fusebox A under the glove compartment |
| 5 | 60A | Circuit breaker: central electrical module in the cargo area |
| 6 | 40A | Climate system blower |
| 7 | - | - |
| 8 | - | - |
| 9 | 30A | Starter motor relay |
| 10 | 50A | Internal diode |
| 11 | 70A | Auxiliary battery |
| 12 | 15A | Central electrical module: auxiliary battery reference voltage, auxiliary battery charging point |
Luggage compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 30A | Electric parking brake (left side) |
| 2 | 30A | Electric parking brake (right side) |
| 3 | 30A | Heated rear window |
| 4 | 15A | Trailer socket 2* |
| 5 | 30A | Power tailgate* |
| 6 | - | - |
| 7 | - | - |
| 8 | - | - |
| 9 | - | - |
| 10 | - | - |
| 11 | 40A | Trailer socket 1* |
| 12 | - | - |
* Option/accessory
