Škoda Rapid 2018 Fuse Box Info
Fuse box location:
The fuse box is located on the bottom of the dash panel behind a cover.
Engine compartment fuse box:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Functions |
| 1 | Light - left |
| 2 | Central locking, front and rear window washer system (only with KESSY or heated windscreen) |
| 3 | Ignition |
| 4 | Light - right |
| 5 | Power windows - driver |
| 6 | Interior lighting |
| 7 | Horn |
| 8 | Towing hitch - left light |
| 9 | Operating lever beneath the steering wheel, engine control unit (only without KESSY), automatic gearbox (only without KESSY), automatic gearbox (only without KESSY), ESC (only without KESSY), towing equipment (only without KESSY), power steering (only without KESSY) |
| 10 | Power windows - rear left |
| 11 | Headlight cleaning system |
| 12 | Infotainment display |
| 13 | Multifunction unit for taxi vehicles |
| 14 | Operating lever under the steering wheel, light switch, ignition key removal lock (automatic gearbox), headlight flasher, rain sensor, reversing camera |
| 15 | Air conditioning, automatic gearbox, diagnostic connector, heated windscreen |
| 16 | Instrument cluster, emergency call |
| 17 | Anti-theft alarm, horn |
| 18 | Heating of the rear seats |
| 19 | Not assigned |
| 20 | Not assigned |
| 21 | Not assigned |
| 22 | Front and rear window washer system (without KESSY or without heated windscreen) |
| 23 | Heated front seats |
| 24 | Blower fan for air conditioning system, heating, air conditioning, heating |
| 25 | Not assigned |
| 26 | Heated front seats |
| 27 | Rear window wiper |
| 28 | Not assigned |
| 29 | Airbag |
| 30 | Electric windows, reverse light switches, air conditioning system, Park Assist, exterior mirror settings, power feed for centre button strip, power feed for side button strip, interior mirror, switch for hazard warning lights |
| 31 | Fuel pump, radiator fan, cruise control, front and rear window washer, light switch |
| 32 | Diagnostic connector, headlight levelling, control lever under the steering wheel, voltage stabiliser for taxi vehicles |
| 33 | Engine starting, clutch pedal switch |
| 34 | Heated windscreen washer jets |
| 35 | Not assigned |
| 36 | USB charge function |
| 37 | Radar |
| 38 | Not assigned |
| 39 | Electrical auxiliary heating system |
| 40 | Not assigned |
| 41 | Rear window heater |
| 42 | Power windows - front passenger |
| 43 | Towing hitch |
| 44 | Cigarette lighter, 12-volt outlet in the interior, 12-volt power socket in the luggage compartment |
| 45 | Power windows - rear right |
| 46 | Front and rear window washer, operating lever under the steering wheel |
| 47 | Towing hitch |
| 48 | Towing hitch |
| 49 | Fuel pump |
| 50 | Infotainment |
| 51 | Heating of the external mirror |
| 52 | KESSY |
| 53 | Steering lock (KESSY) |
| 54 | ABS or ESC |
| 55 | Not assigned |
| 56 | Not assigned |
| 57 | Not assigned |
| 58 | Heating of the rear seats |
| 59 | Not assigned |
Engine compartment fuse box:
| Fuse/Relay N° | Functions |
| 1 | Radiator fan |
| 2 | Glow plug system |
| 3 | ABS or ESC |
| 4 | Additional electrical heating, heated windscreen |
| 5 | Additional electrical heating, heated windscreen |
| 6 | Automatic gearbox |
| 7 | Engine control system |
| 8 | Windscreen wipers |
| 9 | Battery data module |
| 10 | ABS or ESC |
| 11 | Vacuum pump for the brake system |
| 12 | Injectors, valve for fuel metering, control valve for fuel pressure |
| 13 | Brake pedal switch |
| 14 | Fuel pump, radiator fan, cooling pump, pump for intercooling |
| 15 | Engine control system, voltage stabiliser for taxi vehicles |
| 16 | Starter |
| 17 | Engine control system |
| 18 | Additional electric heater, valve for intake manifold, supercharger regulator, oil temperature, valve for activated charcoal filter, valve for oil pressure control |
| 19 | Lambda probe |
| 20 | Glow plug system, crankcase ventilation heater |
