Škoda Karoq 2020 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located under the instrument panel behind the coin tray on the driver’s side.
Engine compartment fuse box location:
Fuse arrangement in engine compartment.
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Functions |
| 1 | SCR (AdBlue®) |
| 2 | Heated steering wheel |
| 3 | Not used |
| 4 | Not used |
| 5 | Databus |
| 6 | Alarm system sensor |
| 7 | Air conditioning front/rear, auxiliary heater receiver, rear window heating, automatic gearbox, ignition key lock (vehicle with automatic transmission) |
| 8 | Light switch, rain sensor, parking brake, ambient lighting, headlights |
| 9 | Control lever under the steering wheel |
| 10 | Infotainment screen |
| 11 | Light - left side |
| 12 | Infotainment |
| 13 | Belt tensioner - left side |
| 14 | Blower fan for air conditioning, heating |
| 15 | Electric steering lock |
| 16 | USB port, diagnostic connector, Phonebox |
| 17 | Instrument cluster, emergency call |
| 18 | Rear view camera, Area View |
| 19 | KESSY (keyless locking and starting system) |
| 20 | SCR (AdBlue®), braking system |
| 21 | All-wheel drive |
| 22 | Tow hitch |
| 23 | Panorama sliding/tilting roof |
| 24 | Light - right side |
| 25 | Central locking- front and rear door left, power window - left, exterior mirrors left - heating, fold-in function, setting the mirror surface |
| 26 | Heating of the front seats |
| 27 | Interior lighting |
| 28 | Tow hitch |
| 29 | USB charging function - rear and on the interior mirror |
| 30 | Not used |
| 31 | Opening the boot lid |
| 32 | Parking aid, Park Assist, "blind spot" detection |
| 33 | Airbag |
| 34 | Air conditioning, reversing light switch, interior mirror with automatic dimming, heated seats, parking brake, light switch, strip with buttons, sports sound generator |
| 35 | Diagnostic connection, front camera, distance monitoring (e.g. ACC, Front Assist) |
| 36 | LED headlight - right |
| 37 | LED headlight - left |
| 38 | Tow hitch |
| 39 | Central locking - front and rear door right, power windows - right, right external mirror - heating, folding function, mirror surface adjustment |
| 40 | 12-volt power outlets |
| 41 | Belt tensioner – right side |
| 42 | Locking (luggage compartment lid, rear doors, fuel filler flap), headlight cleaning system, front and rear windscreen washer |
| 43 | Music amplifier |
| 44 | Tow hitch |
| 45 | Electrical operation of driver's seat |
| 46 | 230 volt sockets |
| 47 | Rear window wiper |
| 48 | Not used |
| 49 | Engine start, clutch pedal switch |
| 50 | Not used |
| 51 | Seat heating - rear |
| 52 | Shock absorber adjustment (adaptive suspension) |
| 53 | Heated rear window |
Engine compartment fuse box:
| Fuse/Relay N° | Functions |
| 1 | ESC, parking brake |
| 2 | ESC |
| 3 | Engine control system |
| 4 | Engine components |
| 5 | Engine components |
| 6 | Brake sensor |
| 7 | Engine components |
| 8 | Lambda probe, NOx sensor |
| 9 | Engine components |
| 10 | Fuel pump |
| 11 | Electric auxiliary heater |
| 12 | Electric auxiliary heater |
| 13 | Oil pump for automatic gearbox |
| 14 | Heated windscreen |
| 15 | Horn |
| 16 | Ignition, fuel pump |
| 17 | ESC, engine control unit, main relay coil |
| 18 | Databus, battery data module |
| 19 | Windscreen wipers |
| 20 | Alarm system |
| 21 | Automatic gearbox |
| 22 | Engine control system |
| 23 | Starter |
| 24 | Electric auxiliary heater |
| 31 | Vacuum pump for the brake system |
| 32 | Not used |
| 33 | Not used |
| 34 | Not used |
| 35 | Not used |
| 36 | Not used |
| 37 | Auxiliary heating |
| 38 | Not used |
