Škoda Karoq 2018 Fuse Box Info
Fuse box location:
The fuse box is on the driver-side dash panel.
Engine compartment fuse box:
Fuse arrangement in engine compartment.
Fuse Box Diagram | Layout
Passenger compartment fuse box:
Fuse/Relay N° | Functions |
1 | SCR (AdBlue®) |
2 | Heated steering wheel |
3 | Not assigned |
4 | Not assigned |
5 | Databus |
6 | Sensor Alarm |
7 | Air conditioning, receiver for the remote control for the auxiliary heating, heated rear window, automatic gearbox |
8 | Light switch, rain sensor, parking brake, background lighting, front headlights |
9 | Operating lever underneath the steering wheel |
10 | Infotainment screen |
11 | Light - left |
12 | Infotainment |
13 | Left side belt tensioner |
14 | Air blower for air conditioning,heating |
15 | Electric steering lock |
16 | USB port, diagnostic connector, Phonebox |
17 | Instrument cluster, emergency call |
18 | Reversing camera |
19 | KESSY system |
20 | SCR (AdBlue®) |
21 | All-wheel drive |
22 | Towing hitch |
23 | Panoramic tilting / sliding sunroof |
24 | Light - right |
25 | Central locking- front and rear door left, power window - left, exterior mirrors left - heating, fold-in function, setting the mirror surface |
26 | Heated front seats |
27 | Interior lighting |
28 | Towing hitch |
29 | Not assigned |
30 | Not assigned |
31 | Opening the boot lid |
32 | Parking aid (Park Assist) |
33 | Airbag |
34 | Air conditioning, reversing light switch, mirror with automatic dimming, seat heating, parking brake, light switches, bar with buttons, USB ports, sport sound generator |
35 | Diagnostics connector, front camera, distance monitoring system (e.g. ACC, Front Assist) |
36 | LED spotlight - right |
37 | LED spotlight - left |
38 | Towing hitch |
39 | Central locking- front and rear door right, power window - right, exterior mirrors right - heating, fold-in function, setting the mirror surface |
40 | 12 volt sockets |
41 | Right side belt tensioner |
42 | Luggage compartment lock, rear door lock, tank flap lock, headlight cleaning system, front and rear windscreen washer system |
43 | Music amplifier |
44 | Towing hitch |
45 | Electrical operation of driver's seat |
46 | 230 volt sockets |
47 | Rear window wiper |
48 | “Blind spot” detection |
49 | Engine starting, clutch pedal switch |
50 | Not assigned |
51 | Heating of the rear seats |
52 | Shock absorber adjustment (adaptive suspension) |
53 | Heated rear window |
Engine compartment fuse box:
Fuse/Relay N° | Functions |
1 | ESC, parking brake |
2 | ESC |
3 | Engine control system |
4 | Radiator fan, oil level and oil temperature sensor, additional electric heating system, SCR (AdBlue®), pre-heating unit, air mass meter, engine components |
5 | Engine components |
6 | Brake sensor |
7 | Coolant pump, exhaust flap, crankcase ventilation, engine components |
8 | Lambda sensor, NOx sensor |
9 | Engine components |
10 | Fuel pump |
11 | Electrical auxiliary heating system |
12 | Electrical auxiliary heating system |
13 | Oil pump for automatic gearbox |
14 | Heated windscreen |
15 | Horn |
16 | Not assigned |
17 | ESC, engine control unit, main relay coil |
18 | Databus, battery data module |
19 | Windscreen wipers |
20 | Anti-theft alarm |
21 | Automatic gearbox |
22 | Engine control system |
23 | Starter |
24 | Electrical auxiliary heating system |
31 | Vacuum pump for the brake system |
32 | Not assigned |
33 | Not assigned |
34 | Not assigned |
35 | Not assigned |
36 | Not assigned |
37 | Aux. heating |
38 | Not assigned |
