Saab 9-3 2008 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located on the end of the instrument panel on the driver’s side of the vehicle.
Engine compartment fuse box location:
Luggage compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 15A | Steering wheel lock |
| 2 | 5A | Steering column unit; ignition switch |
| 3 | 10A | Hands-free |
| 4 | 10A | Main instrument unit; automatic climate control (ACC) |
| 5 | 7.5A | Control module in front doors; Park Brake Shift Lock (automatic transmission) |
| 6 | 7.5A | Brake light switch |
| 7 | 20A | Dash fuse panel; fuel filler door |
| 8 | 30A | Control module in passenger front door |
| 9 | 10A | Dash fuse panel |
| 10 | 30A | Trailer socket; electrical socket in storage compartment between seats |
| 11 | 15A | Data link connection (diagnostics) |
| 12 | 15A | Interior lighting incl. glove box |
| 13 | 30A | Accessories |
| 14 | 20A | Amplifier, Sound System |
| 15 | 30A | Control module in driver’s door |
| 16 | 5A | Passenger Sensing System |
| 17 | - | - |
| 18 | - | - |
| 19 | - | - |
| 20 | 7.5A | Headlight levelling switch |
| 21 | 7.5A | Hands-free; brake light switch; manual climate control; clutch pedal switch |
| 22 | 30A | Cigarette lighter |
| 23 | 40A | Cabin fan |
| 24 | 7.5A | Airbag control module |
| 25 | - | - |
| 26 | 5A | Yaw sensor (cars with ESP) |
| 27 | - | - |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| Fuses | ||
| 1 | - | - |
| 2 | 10A | Engine control module; automatic transmission control module |
| 3 | 20A | Horn |
| 4 | 10A | Engine control module; battery disconnect switch |
| 5 | - | - |
| 6 | 10A | Selector lever, automatic transmission; clutch pedal switch |
| 7 | 10A | Xenon Cornering Headlights, left |
| 8 | 5A | Relay for vacuum pump (brake system) |
| 9 | - | - |
| 10 | - | - |
| 11 | - | - |
| 12 | 10A | Washer fluid pump, rear window |
| 13 | - | - |
| 14 | - | - |
| 15 | 30A | Washer fluid pump, headlights |
| 16 | 30A | Front right parking light; front right turn signal; left and right side turn signal; right high beam; left low beam; front left fog light |
| 17 | 30A | Windshield wiper motor, low speed |
| 18 | 30A | Windshield wiper motor, high speed |
| 19 | 20A | Parking heater; auxiliary heater |
| 20 | 10A | Headlight levelling xenon cornering headlights, right |
| 21 | - | - |
| 22 | 30A | Washer fluid pump, windshield |
| 23 | - | - |
| 24 | 20A | Flash-to-pass; high beam, right and left (cars with Daytime Running Lights only) |
| 25 | 20A | Amplifier, sound system II |
| 26 | 30A | Front left turn signal; front left parking light; front right fog light; right low beam; left high beam |
| 27-37 | MAXI | - |
| Relays | ||
| 1 | - | Washer fluid pump, windshield |
| 2 | - | - |
| 3 | - | - |
| 4 | - | - |
| 5 | - | Flash-to-pass |
| 6 | - | Horn |
| 7 | - | - |
| 8 | - | Starter motor |
| 9 | - | Windshield wipers ON/OFF |
| 10 | - | Washer fluid pump, rear window |
| 11 | - | Ignition +15 |
| 12 | - | Windshield wipers, high/low speed |
| 13 | - | - |
| 14 | - | Washer fluid pump, headlights |
| 15 | - | - |
| 16 | - | - |
Fuse box in front of battery:
| Fuse/Relay N° | Rating | Functions |
| Fuses | ||
| 1 | - | Air pump, secondary air |
| 2 | 20A | Fuel pump; preheated oxygen sensors (lambda probe) |
| 3 | 10A | A/C compressor |
| 4 | 30A | Main relay |
| Relays | ||
| 1 | - | - |
| 2 | - | A/C-compressor |
| 3 | - | Preheated oxygen sensors (lambda probe) |
| 4 | - | Main relay, engine (ECM/EVAP/injectors) |
Luggage compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1-5 | MAXI | - |
| 6 | 30A | Control module in left rear door |
| 7 | 30A | Control module in right rear door |
| 8 | 20A | Trailer |
| 9 | - | - |
| 10 | 30A | Left-hand brake light; rear right turn signal; right tail light; right reversing light; high-mounted brake light; trailer lights |
| 11 | - | - |
| 12 | - | - |
| 13 | - | - |
| 14 | - | - |
| 15 | 15A | Seat heating, left seat |
| 16 | 15A | Seat heating, right seat |
| 17 | 7.5A | Autodimming rearview mirror; rain sensor |
| 18 | 15A | Moonroof |
| 19 | - | - |
| 20 | 7.5A | XM-radio, TMC-tuner |
| 21 | 7.5A | Saab Parking Assistance (SPA); control module in rear doors; dome light (Convertible) |
| 22 | 30A | Radio; navigation |
| 23 | 7.5A | TPMS (automatic tire pressure monitoring system) |
| 24 | 10A | Movement sensor; tilt sensor; dome light (Convertible) |
| 25 | 30A | Electrically adjustable driver’s seat with memory |
| 26 | 30A | Right-hand stop light; rear left turn signal; left taillight; rear fog light; left reversing light; license plate lighting; trunk lighting; trailer lights |
| 27 | 10A | Convertible: Lumbar support, electrically adjustable front seat |
| 28 | 15A | Telematics |
| 29 | - | - |
