Saab 9-5 2001 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located on the end of the instrument panel on the driver’s side of the vehicle. The instrument panel relay box is located on the driver's side under the instrument panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| A | 25A | Trailer lights |
| B | 10A | Automatic transmission |
| C | 7.5A | Electric door mirrors; DICE |
| 1 | 15A | Brake lights; shift-lock override |
| 2 | 15A | Reversing lights |
| 3 | 10A | Parking lights, left |
| 4 | 30A | Parking lights, right |
| 5 | 7.5A | DICE / TWICE |
| 6 | 30A | Electric windows, right |
| 6B | 5A | Stop lights, trailer |
| 7 | 10A | Fuel injection |
| 8 | 15A | Trunk lighting; trunk lock; door lighting; SID; car phone |
| 9 | 15A | Audio System; diagnostic instrument; CD changer |
| 10 | 15A | Memory function, door mirrors; heating, rear seat |
| 11 | 30A | Central locking; electrically adjusted passenger seat |
| 12 | 7.5A | Automatic transmission |
| 13 | 20A | Audio System, amplifier |
| 14 | 30A | Ignition system, engine |
| 15 | 15A | Preheated oxygen sensor (catalytic converter) |
| 16 | 20A | DICE (direction indicators) |
| 16B | - | - |
| 17 | 20A | Engine-management system |
| 18 | 7.5A | Door-mirror heating |
| 19 | 20A | Fuel pump |
| 20 | 15A | ACC; interior lighting; rear fog light |
| 21 | 10A | Audio System; rear-view mirror with auto dimming function; telematics |
| 22 | 40A | Interior fan; air pump (3.0t V6 only) |
| 23 | 15A | Sunroof |
| 24 | 40A | Rear-window heating |
| 25 | 30A | Electrically adjustable driver’s seat; fuel-filler flap |
| 26 | 7.5A | ABS brakes; ACC |
| 27 | 10A | Engine-management system |
| 28 | 7.5A | Airbag (SRS) |
| 29 | 7.5A | Automatic transmission |
| 30 | 7.5A | Starter motor |
| 31 | 7.5A | Cruise control; water valve; fog lights, front |
| 32 | 15A | Ventilated front seats |
| 33 | 7.5A | Direction-indicator switch |
| 34 | 30A | Cigarette lighter |
| 35 | 15A | Daytime running light |
| 36 | 30A | Electric windows, left |
| 37 | 30A | Windshield wipers; rain sensor |
| 38 | 30A | Electric heating, front seats |
| 39 | 20A | Limp-home solenoid (automatic transmission) |
| 52-56 | - | Spare fuses |
Passenger compartment relay box:
| Fuse/Relay N° | Rating | Functions |
| A | - | - |
| B | - | Electric heating of rear seat |
| C | - | - |
| D | - | - |
| E | - | Main relay (engine management system) |
| F | - | Fuel filler flap |
| G | - | Fuel pump |
| H | - | Ignition switch |
| I | - | Rear-window / door mirrors heating |
| J | - | Reversing lights |
| K | - | Starter relay |
| L | - | Limp-home function |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| Fuses | ||
| 1 | 60A | ABS (Maxi fuse) |
| 2 | - | - |
| 3 | 15A | Horn |
| 4 | 10A | Rear window wiper (9-5 Wagon) |
| 5 | 15A | Fog lights (front spoiler) |
| 6 | 30A | Radiator fan, high speed |
| 7 | 15A | Low beam headlight, right |
| 8 | 15A | High beam headlight, right |
| 9 | 15A | Low beam headlight, left |
| 10 | 15A | High beam headlight, left |
| 11 | 10A | Headlight beam-length adjustment (certain markets only); headlamp washers / wipers |
| 12 | - | Spotlights (accessory) |
| 13 | 15A | High beam flasher |
| 14 | 10A | A/C; car alarm siren |
| 15 | 30A | Radiator fan |
| 16 | - | - |
| 17 | - | - |
| 18 | - | - |
| Relays | ||
| 1 | - | Washer, front/rear |
| 2 | - | Low beam headlight |
| 3 | - | High beam headlight |
| 4 | - | Extra lights (accessory) |
| 5.1 | - | Horn |
| 5.2 | - | Rain sensor |
| 6 | - | Wiper, rear (9-5 Wagon) |
| 7 | - | Radiator fan, low speed |
| 8 | - | Radiator fan, high speed, left fan |
| 9 | - | A/C-compressor |
| 10.1 | - | Front fog lights |
| 10.2 | - | Headlamp wipers |
| 11 | - | Windshield wipers |
| 12 | - | Radiator fan, high speed, right fan |
| 13 | - | Autochecking of headlights |
