Saab 9-3 2006 Fuse Box

Saab 9-3 2006 Fuse Box Info



Passenger compartment fuse box location:

The instrument panel fuse box is located on the end of the instrument panel on the driver’s side of the vehicle.



Engine compartment fuse box location:





Luggage compartment fuse box location:





Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Rating Functions
1 15A Steering wheel lock
2 5A Steering column unit; ignition switch
3 10A Hands-free; CD-player/CD-changer in cabin; SID
4 10A Main instrument unit; manual climate control; automatic climate control (ACC)
5 7.5A Control module in front doors; Park Brake Shift Lock (automatic transmission)
6 7.5A Brake light switch
7 20A Dash fuse panel; fuel filler door
8 30A Control module in passenger front door
9 10A Dash fuse panel
10 30A Trailer socket; electrical socket in storage compartment between seats
11 15A Data link connection (diagnostics)
12 15A Interior lighting incl. glove box
13 30A Accessories
14 20A Radio, sound system I; control panel, Infotainment System
15 30A Control module in driver’s door
16 5A Passenger Sensing System
17 - -
18 7.5A Manual climate control
19 - -
20 7.5A Headlight levelling switch
21 7.5A Hands-free; brake light switch; manual climate control; clutch pedal switch
22 30A Cigarette lighter
23 40A Cabin fan
24 7.5A Airbag control module
25 - -
26 5A Yaw sensor (cars with ESP)
27 - -



Engine compartment fuse box:

Fuse/Relay N° Rating Functions
Fuses
1 - -
2 10A Engine control module; automatic transmission control module
3 20A Horn
4 10A Engine control module; battery disconnect switch
5 - -
6 10A Selector lever, automatic transmission; clutch pedal switch
7 - -
8 5A Relay for vacuumpump (brake system)
9 - -
10 - -
11 - -
12 10A Washer fluid pump, rear window
13 - -
14 - -
15 30A Washer fluid pump, headlights
16 30A Front right parking light; front right turn signal; left and right side turn signal; right high beam; left low beam; front left fog light
17 30A Windshield wiper motor, low speed
18 30A Windshield wiper motor, high speed
19 20A Parking heater; auxiliary heater
20 10A Headlight levelling
21 - -
22 30A Washer fluid pump, windshield
23 - -
24 20A Flash-to-pass
25 20A Amplifier, sound system II
26 30A Front left turn signal; front left parking light; front right
fog light; right low beam; left high beam
27-37 MAXI -
Relays
1 - Washer fluid pump, windshield
2 - -
3 - -
4 - -
5 - Flash-to-pass
6 - Horn
7 - -
8 - Starter motor
9 - Windshield wipers ON/OFF
10 - Washer fluid pump, rear window
11 - Ignition +15
12 - Windshield wipers, high/low speed
13 - -
14 - Washer fluid pump, headlights
15 - -
16 - -



Fuse box in front of battery:

Fuse/Relay N° Rating Functions
Fuses
1 - Air pump, secondary air
2 20A Fuel pump; preheated oxygen sensors (lambda probe)
3 10A A/C compressor
4 30A Main relay
Relays
1 - -
2 - A/C-compressor
3 - Preheated oxygen sensors (lambda probe)
4 - Main relay, engine (ECM/EVAP/injectors)



Luggage compartment fuse box:

Fuse/Relay N° Rating Functions
1-5 MAXI -
6 30A Control module in left rear door
7 30A Control module in right rear door
8 20A Trailer
9 - -
10 30A Left-hand brake light; rear right turn signal; right tail light; right reversing light; high-mounted brake light; trailer lights
11 - -
12 - -
13 - -
14 - -
15 15A Seat heating, left seat
16 15A Seat heating, right seat
17 7.5A Autodimming rearview mirror; rain sensor
18 15A Sunroof
19 7.5A Telematics (OnStar)
20 7.5A DVD player (navigation system)
21 7.5A Saab Parking Assistance (SPA); control module in rear doors
22 30A Amplifier, sound system III
23 - -
24 10A Movement sensor; CD changer in trunk
25 30A Electrically adjustable driver’s seat with memory
26 30A Right-hand stop light; rear left turn signal; left taillight; rear fog light; left reversing light; license plate lighting; trunk lighting; trailer lights
27 10A Convertible: Lumbar support, electrically adjustable front seat
28 15A Telematics
29 - -
