Saab 9-3 2000 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located on the end of the instrument panel on the driver’s side of the vehicle. The instrument panel relay box is located on the driver's side under the instrument panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| A | - | - |
| B | 10A | Stop lights, trailer |
| C | 30A | Cabin fan, ACC |
| 1 | 30A | Electrically heated rear window and rear-view mirrors |
| 2 | 20A | Direction indicators |
| 3 | 30A | Cabin fan, A/C |
| 4 | 15A | Trunk light; switch illumination; electrically powered radio antenna |
| 5 | 30A | Electrically operated front seat, right |
| 6 | 30A | Cigarette lighter |
| 6A | 7.5A | Automatic transmission |
| 7 | 30A | Rear window operators, rear-view mirrors, sunroof |
| 8 | 15A | Rear wiper |
| 9 | 7.5A | ACC panel |
| 10 | - | - |
| 11 | 7.5A | DICE / TWICE |
| 12 | 20A | Stop lights; front fog light |
| 13 | 15A | Diagnostics; radio |
| 14 | 30A | Front window motors |
| 15 | 20A | Daytime running lights |
| 16 | 30A | Electrically operated front seat, left |
| 16B | 30A | Control module, engine management system |
| 17 | 15A | DICE/TWICE; instruments; memory for electrically operated driver’s seat |
| 18 | 10A | Airbag |
| 19 | 10A | ABS; A/C; rear fog light |
| 20 | 20A | Electric heating, front seats |
| 21 | 10A | Manual A/C; soft top (Convertible) |
| 22 | 15A | Cruise Control; direction indicators |
| 23 | 20A | Soft top (Convertible); telephone |
| 24 | 7.5A | Radio |
| 25 | 30A | Central locking |
| 26 | 30A | Control module, engine management system; ignition cassette |
| 27 | 15A | High beam flash; ACC |
| 28 | 10A | Engine management system |
| 29 | 10A | Right parking light; number-plate lighting |
| 30 | 10A | Left parking light |
| 31 | 20A | Reversing light; windshield wipers; headlight beam-length adjustment |
| 32 | 15A | Fuel pump |
| 33 | 15A | Electric heating of rear seat |
| 34 | 10A | SID; control module; automatic transmission |
| 35 | 15A | DICE/TWICE; main instrument panel; interior lighting |
| 36 | 10A | Relay, starter |
| 37 | - | - |
| 38 | 25A | Oxygen sensor (lambda probe) |
| 39 | - | - |
Passenger compartment relay box:
| Fuse/Relay N° | Rating | Functions |
| A | - | Electric heating of rear seat |
| B | - | Reversing light, cars with automatic transmission |
| C1 | - | - |
| C2 | - | Lock motor, trunk lid |
| D1 | - | Rear wiper |
| D2 | - | Rear-window washing |
| E | - | Ignition switch |
| F | - | - |
| G | - | Windshield wipers (intermittent) |
| H | - | Rear-window heating |
| I | - | Fuel pump |
| J | - | - |
| K | - | Starter relay |
| L | - | Main relay (injection system) |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 10A | Horn |
| 2 | 10A | Front fog lights |
| 3 | 40A | Radiator fan, low speed |
| 4 | 10A | Vacuum pump |
| 5 | 15A | A/C-compressor |
| 6 | 10A | Left low beam |
| 7 | 10A | Right low beam |
| 8 | 10A | Left high beam |
| 9 | 10A | Right high beam |
| 10 | 7.5A | Headlight wipers |
| 11 | - | - |
| 12 | - | Extra lights |
| 13 | 7.5A | APC |
| 14 | 10A | Extra heater; water pump (Europe) |
| 15 | 15A | Extra heater (Europe) |
| MAXI1 | 30A | Radiator fan, high speed |
| MAXI2 | 50A | ABS |
| A | - | Low beam |
| B | - | High beam |
| C1 | - | Extra heater (Europe) |
| C2 | - | Vacuum pump (Turbo aut.) |
| D | - | Radiator fan, low speed |
| E | - | Lamp check (filament monitor, front) |
| F1 | - | - |
| F2 | - | - |
| G1 | - | Horn |
| G2 | - | Front fog lights |
| H | - | - |
| I | - | Radiator fan, high speed |
| J | - | A/C-compressor |
