Pontiac Firebird 1996 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located on the end of the instrument panel on the driver’s side.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Functions |
| 1. STOP/HAZARD | Hazard Flasher, Brake Switch Assembly |
| 2. TURN B-U | Performance/Traction Control Switch, Transmission Range Switch, Back-up Lamp Switch, Turn Flasher, Daytime Running Lamps (DRL) Module |
| 3. PCM BATT | Powertrain Control Module (PCM), Fuel Pump Relay |
| 4. RADIO ACCY | Radio, Power Antenna, Bose Relay, Remote Compact Disc Changer |
| 5. TAIL, LTS | Daytime Running Lamps (DRL) Module, Headlamp Switch |
| 6. HVAC | HVAC Selector Switch, Rear Defogger TimerRelay, Rear Defogger Switch, Rear Defogger Switch/Timer |
| 7. PWR ACCY | Park Lamp Relay, Hatch Release Relay, Power Mirror Switch, Radio, Shock Sensor, Instrument Cluster |
| 8. COURTESY | Body Control Module (BCM) |
| 9. GAGES | Body Control Module (BCM), Brake Switch Assembly (BTSI), Instrument Cluster, Daytime Running Lamps (DRL) Module, Auxiliary Accessory Wire |
| 10. AIR BAG | Air Bag System, Dual Pole Arming Sensor |
| 11. CIGAR/ACCY | Cigarette Lighter, Data Link Connector (DLC), Auxiliary Accessory Wire |
| 12. DEFOG/SEATS | Rear Defogger Switch/Timer, Rear Defogger Timer/Relay, Power Seats |
| 13. PCM IGN | Powertrain Control Module (PCM), EVAP Canister Purge Vacuum Switch, EVAP Canister Purge Valve, Transmission |
| 14. WIPER/WASH | Wiper Motor Assembly, Wiper/Washer Switch |
| 15. WINDOWS | Power Windows Switch (RH, LH), Express-Down Module, Coolant Level Latching Module, Convertible Top Switch |
| 16. I/P DIMMER | Door Illumination Lamp (RH, LH), Headlamp Switch, Fog Lamp Switch, Instrument Cluster, HVAC Control Assembly, PRNDL Illumination Lamp, Ashtray Lamp, Radio, Steering Wheel Controls-Radio, Rear Window Defogger Switch/Timer, Performance/Traction Control Switch |
| 17. RADIO | Body Control Module (BCM), Radio, Amplifier, Steering Wheel Controls-Radio |
Engine compartment fuse box:
| Fuse/Relay N° | Functions |
| 1. ABS IGN | Anti-Lock Brake System |
| 2. ACTUATORS | Daytime Running Lamp Module, Headlamp Switch, Cooling Fan Relay, Exhaust, Gas Recirculation, EVAP Canister Purge Solenoid |
| 3. R HDLP DR | Headlamp Door Module |
| 4. L HDLP DR | Headlamp Door Module |
| 5. ABS VLV | Brake Pressure Valve |
| 6. ABS BAT | Electronic Brake Control Module |
| 7. AIR PUMP/FAN | Air Pump (V8) Relay, Pump, Bleed Valve and Cooling Fan |
| 8. HORN | Horn Relay |
| 9. INJECTOR | Fuel Injectors |
| 10. ENG SEN | Mass Airflow, Heated Oxygen Sensor, Reverse Lockout Solenoid, Skip Shift Solenoid, Automatic Transmission, Brake Switch |
| 11. IGNITION | V6 VIN K: Electronic Ignition Module; V8 VIN P: Ignition Coil Module, Crankshaft Position Sensor, Ignition Coil |
| 12. A/C-CRUISE | Air Conditioning Compressor Relay, Cruise Control Switches and Module |
| B | Air Conditioning Compressor |
| C | Anti-Lock Brake System/Traction Control System (TCS) |
| D | Cooling Fan Number 1 |
| E | Air Pump |
| F | Cooling Fan Number 2 |
| G | Not Used |
| H | Fog Lamps |
| J | Cooling Fan Number 3 |
