Pontiac Firebird 1995 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located on the end of the instrument panel on the driver’s side.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Functions |
| 1. AIR BAG | SIR Components |
| 2. TURN B-U | Backup Lamps, Daytime Running Lamps Module (Canada), Turn Flasher, Transmission Range Switch, Traction Control Switch |
| 3. HVAC | Heat Control Selector Switch (Heatedfir Conditioner), Rear Defogger |
| 4. RADIO ACCY | Power Antenna, Disc Changer |
| 5. PCM IGN | Powertrain Control Module, Fuel Pump Relay, Theft Deterrent Module, Engine Mass Air Flow Sensor (V8 Engine) |
| 6. STOP/HAZARD | Brake Light/Cruise Release Switch, Hazard Flasher |
| 7. PWR ACCY | Power Door Locks, Power Mirrors, Hatch Release Switch, Auxiliary Accessory Wire |
| 8. COURTESY | Audio Alarm Module, Courtesy Lamps: Console Compartment, Glove Box, Dome, Trunk, Rear Courtesy, Rearview Mirror, Radio, Theft Deterrent Module, SECURITY Indicator, Hatch Release Relay, Keyless Entry Receiver |
| 9. GAGES | Audio Alarm Module, Daytime Running Lamps Module (Canada), Diagnostic Energy Reserve Module, Instrument Cluster, Keyless Entry Receiver, Brake Switch Assembly, Auxiliary Accessory Wire |
| 10. TAIL LTS | Exterior Lighting |
| 11. CIGAR/HORN | Cigarette Lighter, Horn Relay, Data Link Connector |
| 12. DEFOG/SEATS | Power Seats, Rear Defogger |
| 13. IP DIMMER | Brightness Control |
| 14. WIPER/WASH | Windshield Wiper/Washer |
| 15. WINDOWS | Power Windows, Convertible Top Switch (CB), Cooling Level Latching Module |
| 16. CRANK | Diagnostic Energy Reserve Module |
| 17. RADIO | Radio Amplifier, Steering Wheel Controls |
Engine compartment fuse box:
| Fuse/Relay N° | Functions |
| 1. ABS BAT | Electronic Brake Control Module |
| 2. FOG LTS | Fog Lamps |
| 3. R HDLP DR | Headlight Doors Module |
| 4. L HDLP DR | Headlight Doors Module |
| 5. ABS IGN | Anti-Lock Brake System |
| 6. FANS/ACTR | Coolant Fan Relays, EVAP Canister Purge Solenoid, Exhaust Gas Recirculation, Reverse Lockout Solenoid, Skip Shift Solenoid, Heated Oxygen Sensors (V8 Engine) |
| 7. AIR PUMP | Air Pump Relay |
| 8. PCM | Powertrain Control Module |
| 9. INJECTOR | Fuel Injectors |
| 10. INJECTOR | Fuel Injectors |
| 11. IGNITION | VIN Engine Code S, Camshaft Position Sensor, Crankshaft Position Sensor, Ignition Control Module, Automatic Transmission, Ignition Coil (V-8 Engine), Ignition Coil Module (V-8 Engine) |
| 12. A/C-CRUISE | Air Conditioning Compressor Relay, Cruise Control Switches and Module |
| B | Air Conditioning Compressor |
| C | Anti-Lock Brake System |
| D | Coolant Fan Number 1 |
| E | Air Pump |
| F | Coolant Fan Number 2 |
| G | Traction Control System |
| H | Fog Lamps |
| J | Coolant Fan Number 3 |
