Pontiac Grand Prix 1998 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located inside of the glove box behind a small bin, on the right side.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay | Functions |
| HEADLMP | Headlamps |
| SEAT | Power Seat, Power Lumbar |
| PWR WDO | Power Windows |
| MALL PGM | Mall Module -- Program |
| MALL | Mall Module |
| WIPER | Wipers |
| STR WHL | Steering Wheel Illumination |
| STR WHL CTR | Steering Wheel Control |
| SUNROOF | Sunroof |
| RADIO | Radio, Antenna |
| PWR LOCK | Mall Module -- Power Locks |
| HSEAT/LUM | Heated Seats, Power Lumbar |
| R DEFOG | Rear Defog |
| RAP | Retained Accessory Power, Mall Module |
| HAZARD | Hazard Flashers |
| PWR MIR | Power Mirrors |
| HVAC HI | HVAC Blower -- Hi |
| CIG LTR | Cigarette Lighter, ALDL, Floor Console Auxiliary Outlet |
| INT LAMP | Mall Module-Interior lamps |
| STOP LAMP | Stoplamp |
| AUX/CNSL | Auxiliary Power, Overhead Console |
| CD CHG | CD Changer |
| ECM | ECM |
| CRUISE | Cruise Control |
| I/P-IGN | Chime/Mall Module, Cluster, Trip Computer, Head-Up Display, Brake-Transaxle Shift Interlock |
| SIR | Supplemental Inflatable Restraint (Air Bag) |
| TURN | Turn Signal |
| ABS | Anti-Lock Brakes |
| BTSI | PRNDL, Brake-Transaxle Shift Interlock |
| PWR DROP | Power Drop Ignition |
| HVAC CTRL | Blower Control, HVAC |
| DIC/HVAC | Rear Defog, HVAC, Driver Information Center, Daytime Running Lamps, Heated Seats |
| CANISTER VENT | Canister Vent Solenoid |
| DRL | Daytime Running Lamps |
Engine compartment fuse box:
| Fuse/Relay | Functions |
| Fuses | |
| COOL FAN 2 | Cool Fan 2 |
| HEADLAMPS | Headlamps |
| BATT MAIN 2 | Battery Main 2 |
| IGN MAIN 1 | Ign Main 1 |
| COOL FAN 1 | Cool Fan 1 |
| BATT MAIN 1 | Ban Main 1 |
| IGN MAIN 2 | Ign Main 2 |
| B/U LP | Trunk Release, Back-up Lamps |
| TRANSMISSION | Automatic Transaxle: Enable, Switch, Shift, PWM |
| FUEL PUMP | Fuel Pump |
| AC CLU/ABS IGN | AC Clutch, ABS Ignition |
| IGN1-UH | MAF, Heated Sensors, Canister Prg, Boost Solenoid |
| IGN MODULE | Ignition Module |
| INJ | Fuel Injectors |
| ECM | ECM/PCM |
| PARK LP | Chime/Mall Module, Taillamps, Parklamps, Sidemarker Lamps, Dimmable Lamps |
| FUTURE | Spare Fuse |
| SPARE | Spare Fuse |
| SPARE | Spare Fuse |
| SPARE | Spare Fuse |
| SPARE | Spare Fuse |
| FOG LP | Fog Lamps |
| FUTURE | Spare Fuse |
| SPARE | Spare Fuse |
| SPARE | Spare Fuse |
| RADIO | Radio, Keyless Entry, Theft Shock Sensor, Trip Computer, HVAC Module, ABS Module, Security LED |
| HORN | Horn |
| ALT SENSE | Alt Sense |
| Diode | |
| AC DIODE | A/C Clu Diod |
| Relays | |
| RELAY COOL FAN SERIES | Cooling Fan |
| RELAY FUEL PUMP (ONLY SUPERCHARGER) | Fuel Pump |
| FUEL PUMP SPEED | Fuel Pump Speed Cont |
| RELAY COOL FAN 2 | Cooling Fan 2 |
| RELAY A/C CLUTCH | A/C Clutch |
| RELAY COOL FAN 1 | Cooling Fan 1 |
| IGN MAIN | Ign Main |
| RELAY HORN | Horn |
| RELAY FOG LP | Fog Lamp |
