Pontiac Grand Prix 1997 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located inside of the glove box behind a small bin, on the right side.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay | Functions |
| HEADLMP | Headlamps |
| PWR SEAT | Power Seat, Power Lumbar |
| PWR WDO | Power Windows |
| MALL PGM | Mall Module -- Program |
| MALL | Mall Module |
| WIPER | Wipers |
| STR WHL ILUM | Steering Wheel Illumination |
| STR WHL CTR | Steering Wheel Control |
| SUNROOF | Sunroof |
| RADIO | Radio, Antenna |
| PWR LOCK | Mall Module -- Power Locks |
| HSEAT/LUM | Heated Seats, Power Lumbar |
| R DEFOG | Rear Defog |
| RAP | Retained Accessory Power, Mall Module |
| HAZARD | Hazard Flashers |
| PWR MIR | Power Mirrors |
| HVAC HI | HVAC Blower -- Hi |
| CIG LTR | Cigarette Lighter, ALDL, Floor Console Auxiliary Outlet |
| INT LAMP | Mall Module-Interior lamps |
| STOP LP | Stoplamp |
| AUX/CNSL | Auxiliary Power, Overhead Console |
| CD CHGR | CD Changer |
| ECM | ECM |
| CRUISE | Cruise Control |
| I/P-IGN | Chime/Mall Module, Cluster, Trip Computer, Head-Up Display, Brake-Transaxle Shift Interlock |
| SIR | Supplemental Inflatable Restraint (Air Bag) |
| TURN | Turn Signal |
| ABS | Anti-Lock Brakes |
| BTSI | PRNDL, Brake-Transaxle Shift Interlock |
| HVAC CTRL | Blower Control, HVAC |
| DIC/HVAC | Rear Defog, HVAC, Driver Information Center, Daytime Running Lamps, Heated Seats |
| ABS IGN | Anti-Lock Brakes Ignition |
| DRL | Daytime Running Lamps |
Engine compartment fuse box:
| Fuse/Relay | Functions |
| FUTURE | Spare |
| PARK LP | Chime/Mall Module, Taillamps, Park Lamps, Sidemarker Lamps, Dimmable Lamps |
| FOG LP | Fog Lamps |
| FUTURE | Spare |
| ECM | ECM/PCM |
| FUEL PMP | Fuel Pump |
| TCC | Automatic Transaxle: Enable, Switch, Shift, PWM |
| ALT | Alt Sense |
| RADIO | Radio, Remote Lock Control, Theft Shock Sensor, Trip Computer, HVAC Module, ABS Module, Security LED |
| AC CLU | AC Clutch |
| B/U LP | Trunk Release, Back-up Lamps |
| IGN MODULE | Ignition Module |
| IGNI-UH | MAF, Heated Sensors, Canister Prg, Boost Solenoid |
| INJ | Fuel Injectors |
