Opel Ampera-E 2019 Fuse Box

Opel Ampera-E 2019 Fuse Box Info



Passenger compartment fuse box location:

The fuse box is located at the left side of the steering column at the bottom of the instrument panel.



Engine compartment fuse box location:







Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Functions
1 Video processing module
2 Indicator light solar sensor
3 Side blind zone alert
4 Passive entry, passive start
5 Central gateway module
6 Body control module 4
7 Body control module 3
8 Body control module 2
9 Body control module 1
10 Trailer interface module 1
11 Amplifier
12 Body control module 8
13 Data link connector 1
14 Automatic parking assist
15 -
16 Single power inverter module 1
17 Body control module 6
18 Body control module 5
19 -
20 -
21 -
22 -
23 USB
24 Wireless charging module
25 Reflected LED alert display
26 Automatic heated steering wheel
27 -
28 Instrument cluster 2
29 Trailer interface module 2
30 Headlight levelling device
31 OnStar
32 -
33 Heating, ventilation, and air conditioning module
34 -
35 Instrument panel cluster 1
36 Radio
37 -
38 -
39 -
40 -
41 -
42 -
43 Body control module 7
44 Sensing and diagnostic module
45 Front camera module
46 Vehicle integration control module
47 Single power inverter module 2
48 Electric steering column lock
49 Auxiliary jack
50 Steering wheel controls
51 Steering wheel controls backlighting
52 Smartphone remote function module
53 Auxiliary power outlet
54 -
55 Logistic
56 -
57 -
58 -
59 -
60 -



Engine compartment fuse box:

Fuse/Relay N° Functions
1 -
2 Power window rear
3 -
4 Rechargeable energy storage system 1
5 -
6 -
7 Left high‐beam headlight
8 Right high‐beam headlight
9 Left low‐beam headlight
10 Right low‐beam headlight
11 Horn
12 -
13 Front wiper motor driver
14 Tailgate
15 Front wiper motor co-driver
16 Electronic brake control module supply electronics
17 Rear wiper
18 Tailgate
19 Seat module front
20 Washer
21 -
22 Linear power module
23 Electronic brake control module supply motor
24 Seat module rear
25 -
26 Transmission range control module
27 Aero shutter
28 Auxiliary oil pump
29 E-booster motor source
30 Front power windows
31 In-panel bussed electrical centre
32 Rear window defogger
33 Heated exterior rear view mirror
34 Pedestrian friendly alert function
35 -
36 -
37 Current sensor
38 Rain sensor
39 -
40 E-booster (ECU)
41 Power line communication module
42 Infant occupant sensing
43 Window switch
44 Rechargeable energy storage system
45 Vehicle integration control module
46 Integrated chassis control module
47 Headlight levelling device
48 Integrated chassis control module
49 Interior rear view mirror
50 -
51 E-booster
52 Rear camera
53 -
54 A/C control module
55 Rechargeable energy storage system pump
56 -
57 Power electronics coolant pump
58 Engine control module
59 Electric steering column lock
60 HVAC electric heater
61 On-board charging module
62 Transmission range control module 1
63 Electric cooling fan
64 Engine control module
65 Auxiliary heater pump
66 -
67 Drive unit controller
68 Rear window defogger
69 -
70 A/C control module
71 -
72 Transmission range control module
73 Single power inverter module
74 -
