Lincoln Continental 2017 Fuse Box Info
Passenger fuse box location:
The fuse box is located under the instrument panel to the left of the steering column.
Engine compartment fuse box:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | - | Not used |
| 2 | 7.5A | Driver seat switch, Passenger seat switch |
| 3 | 20A | Driver unlock relay |
| 4 | 5A | Not used (spare) |
| 5 | 20A | Subwoofer amplifier, Revel digital signal processing amplifier |
| 6 | - | Not used |
| 7 | - | Not used |
| 8 | 10A | Security horn |
| 9 | 10A | Rear seat entertainment module |
| 10 | 5A | Telematics module, Power decklid module |
| 11 | 5A | Keypad, Outside lock switch, Combined security sensor module |
| 12 | 7.5A | Front control interface module (climate control), Gear shift module, Rear climate control module |
| 13 | 7.5A | Instrument cluster, Smart data link, Steering column control module |
| 14 | 10A | Restraints control module |
| 15 | 10A | Smart datalink connector power |
| 16 | - | Decklid release relay |
| 17 | 5A | Not used (spare) |
| 18 | 5A | Push button start switch |
| 19 | 7.5A | LED heads up display |
| 20 | 7.5A | Headlamp control module |
| 21 | 5A | Humidity sensor |
| 22 | 5A | Occupant classification sensor |
| 23 | 10A | Delayed accessory power, Left front window switch, Moonroof, Rear window power sunshade module, DC inverter |
| 24 | 20A | Central lock relay |
| 25 | 30A | Left front door zone module |
| 26 | 30A | Right front door zone module |
| 27 | 30A | Moonroof |
| 28 | 20A | Revel digital signal processing amplifier |
| 29 | 30A | Left rear door zone module |
| 30 | 30A | Right rear door zone module |
| 31 | 15A | Column memory module |
| 32 | 10A | SYNC, Radio frequency receiver |
| 33 | 20A | Radio, Remote CD mechanism |
| 34 | 30A | Run/start relay |
| 35 | 5A | Restraint control module |
| 36 | 15A | Lane keeping system module, Auto high beam, Electrochromic mirrors, Rear heated seats, Vehicle dynamics module |
| 37 | 20A | Heated steering wheel, Steering effort control module, Steering angle control module |
| 38 | 30A | Left hand front window motor, Rear power window motors |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 20A | Powertrain control module power |
| 2 | 20A | Engine emissions (MIL) |
| 3 | 20A | A/C clutch control relay coil, VACC, Active grill shutters, Cooling fan relays, All-wheel drive module (2.7L and 3.7L engines) |
| 4 | 20A | Ignition coils (3.7L engine) |
| 5 | - | Not used |
| 6 | - | Not used |
| 7 | 5A | Rear recline relay box |
| 8 | - | Not used |
| 9 | - | Not used |
| 10 | - | Not used |
| 11 | - | Torque vectoring relay (3.0L engine) |
| 12 | - | Not used |
| 13 | 40A | Rear seat recline |
| 14 | - | Powertrain control module relay |
| 15 | 20A | Horn |
| 16 | 10A | A/C clutch |
| 17 | - | Not used |
| 18 | - | Not used |
| 19 | - | Heated rear window relay |
| 20 | - | Electric cooling fan relay |
| 21 | - | Electric cooling fan relay |
| 22 | 30A | Electric cooling fan |
| 23 | - | Not used |
| 24 | - | Not used |
| 25 | - | Blower motor relay |
| 26 | 30A | Anti-lock brake system valves |
| 27 | - | Not used |
| 28 | 30A | Rear climate controlled seats |
| 29 | - | Run/start relay |
| 30 | - | Not used |
| 31 | 10A | Electric power-assisted steering, Electric parking brake |
| 32 | 10A | Anti-lock brake system module |
| 33 | 10A | Powertrain control module |
| 34 | 10A | Blind spot information system, Adaptive cruise control, Front view camera, 360 degree camera module, Rear camera, Transmission range control module |
| 35 | - | Not used |
| 36 | - | Electric cooling fan relay |
| 37 | - | Rear seat recline relay |
| 38 | - | A/C compressor clutch relay |
| 39 | - | Horn relay |
| 40 | - | Not used |
| 41 | 40A | Right heated windshield |
| 42 | 40A | Blower motor |
| 43 | - | Not used |
| 44 | 50A | Body control module/voltage quality module bus |
| 45 | - | Not used |
| 46 | 50A | Electric cooling fan |
| 47 | 50A | Electric cooling fan |
| 48 | 50A | Body control module RP1 bus |
| 49 | 40A | Torque vectoring (3.0L engine) |
| 50 | 50A | Body control module RP2 bus |
| 51 | - | Not used |
| 52 | 60A | Anti-lock brake system pump |
| 53 | 40A | Adaptive front steering |
| 54 | 40A | Left heated windshield |
| 55 | 40A | Heated rear window |
| 56 | 40A | Power inverter |
| 57 | 30A | Power deck lid module, Manual deck lid latch |
| 58 | - | Not used |
| 59 | - | Not used |
| 60 | 30A | Fuel pump |
| 61 | - | Not used |
| 62 | 20A | Power point 2A |
| 63 | 30A | Power seat control module, Front heated seats |
| 64 | - | Not used |
| 65 | 30A | Fuel pump 2 |
| 66 | 30A | Passenger power seat |
| 67 | 20A | Power point 1B |
| 68 | 15A | Auxiliary blower |
| 69 | 20A | Power point 1A |
| 70 | - | Not used |
| 71 | - | Not used |
| 72 | 30A | Driver power seat module |
| 73 | - | Not used |
| 74 | 25A | Wiper motor |
| 75 | - | Not used |
| 76 | 20A | Not used (spare) |
| 77 | - | Not used |
| 78 | 30A | Starter |
| 79 | - | Not used |
| 80 | - | Not used |
| 81 | 5A | USB smart charge - passenger side |
| 82 | 5A | USB smart charge - console |
| 83 | 20A | Electronic door latch (left rear) |
| 84 | 5A | USB smart charge - driver side |
| 85 | 20A | Electronic door latch (right front) |
| 86 | 20A | Electronic door latch (right rear) |
| 87 | 15A | Transmission range control module |
| 88 | 5A | Rear recline |
| 89 | 20A | Electronic door latch (left front) |
| 90 | 10A | Powertrain control module relay keep alive |
| 91 | 10A | Brake on/off switch |
| 92 | 15A | Front multi-contour seat module |
| 93 | 15A | Rear multi-contour seats |
| 94 | 20A | Right hand side high intensity discharge headlamp |
| 95 | 20A | Left hand side high intensity discharge headlamp |
| 96 | 10A | Wiper park heater |
| 97 | 10A | Alternator sense line |
| 98 | 5A | Rain sensor |
| 99 | - | Not used |
