Jeep Wrangler 2024 Fuse Box Info
Engine compartment fuse box location:
2.0L Engine, 2.0L PHEV Engine, 3.6L Engine
6.4L Engine
Fuse Box Diagram | Layout
Engine compartment fuse box (Gasoline engine):
| Fuse/Relay N° | Rating | Functions |
| 01 | - | Spare* |
| 02 | 40A | Starter |
| 03 | 5A | Intelligent Battery Sensor (IBS) |
| 04 | 20A | Fuel Pump MTR / FPCM |
| 05 | 5A | Security Gateway |
| 06 | - | Spare* |
| 07 | 15A | LTR Coolant Pump* |
| 08 | 15A | TCM-8HP CYGNUS |
| 09 | - | Spare* |
| 10 | 15A | ESCL |
| 11 | 10A | UCI Port (USB & AUX) |
| 12 | 25A | HIFI Amplifier |
| 13 | - | Spare* |
| 14 | - | Spare* |
| 15 | 15A | IPC / Switch Bank-HD Elec |
| 16 | - | Spare* |
| 17 | - | Spare* |
| 18 | 10A | AC Clutch |
| 19 | - | Spare* |
| 20 | 30A | Central Body Controller (CBC) 1-INTERIOR LIGHTS |
| 21 | 20A | REAR WIPER |
| 22 | 10A | ECM / ETC |
| 23 | 10A | ECM |
| 24 | 30A | Pass Pwr Seat |
| 25 | 10A | MOD_SBW |
| 26 | 40A | Central Body Controller (CBC) 2-EXTERIOR LIGHTS #1 |
| 27 | 30A | Front Wipers |
| 28 | 40A | Central Body Controller (CBC) 3-POWER LOCKS |
| 29 | 40A | Central Body Controller (CBC) 4-EXTERIOR LIGHTS #2 |
| 30 | 30A | Power Step/Slider |
| 31 | 10A | DIAGNOSTIC PORT |
| 32 | 10A | HVAC CTRL MOD / SCL / OCM / DPDM |
| 33 | 10A | PTS / IRCM / Airbag Disable Lamps |
| 34 | 10A | ESC / EHPS / SBCM Wake Up |
| 35 | 30A | BRAKE VAC PMP* |
| 36 | 30A | TRAILER TOW ELEC BRK MOD* |
| 37 | 30A | TRAILER TOW CONN 7W* |
| 38 | 20A | ECM |
| 39 | - | Spare* |
| 40 | 15A | DTCM / Axle Lock FT_RR |
| 41 | 15A | IC / SGW Wake Up |
| 42 | 10A | PCR Ctrl Feed (ESS)* |
| 43 | 20A | PWR OUTLET (CARGO) BATT |
| 44 | 10A | IRCAM HEATERS |
| 45 | 20A | PWR OUTLET (CARGO) IGN* |
| 46 | 10A | AUTO HDLP LVL MOD / LVL MTR / HDLP SW |
| 47 | - | Spare* |
| 48 | - | Spare* |
| 49 | 10A | Occupant Restraint Controller (ORC) |
| 50 | 10A | HD ACC* |
| 51 | 10A | Digital TV Inline / USB / ISRVM / Compass Mod |
| 52 | 20A | CIGAR LTR |
| 53 | - | Spare* |
| 54 | - | Spare* |
| 55 | 10A | Central Vision Processing Module (CVPM) |
| 56 | 10A | IN-CAR Temp Sesr /PTC Htr Coil Feed |
| 57 | 20A | Driver Heated Seat |
| 58 | 20A | Pass Heated Seat |
| 59 | 30A | Driver Pwr Seat |
| 60 | 15A | CSWM (Htd Str Wheel) |
| 61 | 15A | LBSS / RBSS / CADM-LO* |
| 62 | 10A | Exhaust Sol* |
| 63 | 10A | ORC |
| 64 | - | Spare* |
| 65 | - | Spare* |
| 66 | 40A | HVAC Blower Mtr Front |
| 67 | - | Spare* |
| 68 | - | Spare* |
| 69 | 10A | KIN / RF Hub |
| 70 | 25A | INJ / IGN COIL |
| 71 | - | Spare* |
| 72 | 10A | HD ELEC ACC PKG* |
| 73 | 20A | PWR TOP LT |
| 74 | 20A | PWR TOP RT |
| 75 | - | Spare* |
| 76 | 20A | ECM |
| 77 | 10A | Heated Mirrors |
| 78 | 10A | Intrusion Mod / SIREN / Intrusion Snsrs |
| 79 | 20A | Smart Bar Ctrl Mod |
| 80 | 15A | SOL 1,2 BLOCK SHIFT* |
| 81 | 30A | Rear Defrost (EBL) |
| 82 | - | Spare* |
| 83 | - | Spare* |
| 84 | - | Spare* |
| 85 | - | Spare* |
| 86 | - | Spare* |
| 87 | - | Spare* |
| 88 | - | Spare* |
| 89 | 10A | SCCM / Cruise Ctl / DTV / EVIC / Airbag Disable Lamp |
| 90 | 20A | Trailer Tow Park Lmp* |
| 91 | 20A | Horn |
| 92 | 40A | HD ACCY #2* |
| 93 | 40A | HD ACCY #1* |
| 94 | 10A | Dual USB Port |
| 95 | - | Spare* |
| 96 | 10A | Pwr Mirror SW |
| 97 | 20A | Radio |
| 98 | 10A | SW BANK-HD ELEC / OFF ROAD |
| 99 | - | Spare* |
| 100 | 30A | ESC-ECU & Valves |
| 101 | 30A | DTCM |
| 102 | 15A | TBM2 / DCSD Mod |
| 103 | 15A | HD ACCY #3* |
| 104 | 15A | Lumbar SW (Driver & Pass) |
| 105 | 10A | ICS / HVAC / ETC |
| 106 | 50A | ESC -Pump Mtr |
| 107 | 20A | Trailer Tow Stop/Turn LT* |
| 108 | 15A | HD ACCY #4* |
| 109 | 20A | Trailer Tow Stop/Turn RT* |
| 110 | 30A | Power Inverter |
| 111 | 20A | Trailer Tow Backup* |
* If Equipped
Engine compartment fuse box (PHEV):
| Fuse/Relay N° | Rating | Functions |
| 01 | 5A | HV Electric Coolant Heater Enable |
| 02 | - | Spare* |
| 03 | 5A | Intelligent Battery Sensor (IBS) |
| 04 | 20A | Fuel Pump MTR / FPCM |
| 05 | 5A | Security Gateway |
| 06 | 10A | BPCM |
| 07 | 15A | PECP-2 (LTR COOLANT PUMP) |
| 08 | 15A | Trans Control Module TCM-8HP CYGNUS |
| 09 | 5A | IDCM |
| 10 | 15A | ESCL |
| 11 | 10A | UCI Port (USB & AUX) |
| 12 | 25A | HIFI Amplifier |
| 13 | 10A | PIM - Redundant Main Pwr Supply |
| 14 | 10A | PIM - Main Pwr Supply |
| 15 | 10A | IPC / Switch Bank-HD ELEC |
| 16 | - | Spare* |
| 17 | 40A | Trans Oil Pump |
| 18 | 10A | Electric Air Conditioning Compressor |
| 19 | 5A | Charge Port Indicator |
| 20 | 30A | CBC 1-INTERIOR LIGHTS |
| 21 | 20A | Rear Wiper* |
| 22 | 10A | ECM / PIM / ETC |
| 23 | - | Spare* |
| 24 | 30A | Pass Power Seat |
| 25 | 10A | MOD_SBW |
| 26 | 40A | CBC 2-EXTERIOR LIGHTS #1 |
| 27 | 30A | Front Wipers |
| 28 | 40A | CBC 3-POWER LOCKS |
| 29 | 40A | CBC 4-EXTERIOR LIGHTS #2 |
| 30 | 30A | Power Step Slider* |
| 31 | 10A | DIAGNOSTIC PORT |
| 32 | 10A | HVAC CTRL MOD / Steering Column Lock (SCL) / Occupant Classification Module (OCM) / Driver Presence Detection Module (DPDM) |
| 33 | 10A | PTS / IRCM MODULE |
| 34 | 10A | Electronic Stability Control (ESC) / Electric Hydraulic Power Steering (EHPS) / Smart Bar Control Module (SBCM) WAKE UP |
| 35 | - | Spare* |
| 36 | 30A | Trailer Tow Electric Brake Mod |
| 37 | 30A | Trailer Tow Conn 7W |
| 38 | 20A | Engine Control Module (ECM) |
| 39 | - | Spare* |
| 40 | 15A | DriveTrain Control Module (DTCM) / Axle Lock FT_RR |
| 41 | 15A | Instrument Cluster (IC) / Security GateWay (SGW) WAKE UP |
| 42 | - | Spare* |
| 43 | 20A | PWR OUTLET (CARGO) BATT |
| 44 | 10A | InfraRed Camera (IRCAM) HEATERS |
| 45 | 20A | PWR OUTLET (CARGO) IGN* |
| 46 | 10A | AUTO HDLP LVL MOD / LVL MTR / HDLP SW |
| 47 | 10A | QVPM - Quiet Vehicle Pedestrian Module |
| 48 | 10A | Spare* |
| 49 | 10A | Occupant Restraint Controller (ORC) |
| 50 | 10A | HD ACC |
| 51 | 10A | DTV / USB / ISRVM / Compass Mod / Inverter 400W */ ECM / PIM |
| 52 | 20A | CIGAR LTR |
| 53 | 10A | Wireless Speaker* |
| 54 | - | Spare* |
| 55 | 10A | CVPM |
| 56 | 10A | IN-CAR TEMP SENSOR |
| 57 | 20A | Driver Heated Seat |
| 58 | 20A | Pass Heated Seat |
| 59 | 30A | Driver Power Seat |
| 60 | 15A | HTD STR WHEEL |
| 61 | 15A | LBSS / RBSS / CADM-LO* |
| 62 | 10A | Spare* |
| 63 | 10A | Occupant Restraint Controller (ORC) |
| 64 | - | Spare* |
| 65 | 50A | Power Inverter 400W |
| 66 | 40A | HVAC Blower Mtr Front |
| 67 | 15A | BCP - Lo Temp Active Pump |
| 68 | - | Spare* |
| 69 | 10A | KIN / RF Hub |
| 70 | 25A | IGN COIL / FUEL INJECTOR |
| 71 | 10A | Battery Coolant Heater |
| 72 | 10A | HD ELEC ACC PKG |
| 73 | 20A | PWR TOP LT* |
| 74 | 20A | PWR TOP RT* |
| 75 | 5A | Battery Charge Indicator / Sw Bank PHEV Mode |
| 76 | 20A | ECM |
| 77 | 10A | Heated Mirrors |
| 78 | 10A | Intrusion Mod / Siren / Intrusion Sensors* |
| 79 | 20A | Smart Bar CTRL Mod |
| 80 | 15A | SOL 1 2 Block Shift / Mod ELCM / SOL Fuel Tank Isolation |
| 81 | 30A | Rear Defrost (EBL) |
| 82 | - | Spare* |
| 83 | 50A | ESC-ECU & Valves |
| 84 | 20A | PIM - High Side Drive Power |
| 85 | 15A | PECP - Lo Temp Passive Pump |
| 86 | - | Spare* |
| 87 | 15A | AHP - Hi Temp Aux Pump |
| 88 | - | Spare* |
| 89 | 10A | SCCM / CRUISE CTL / EVIC / DTV / AIRBAG DISABLE LMP |
| 90 | 20A | TRAILER TOW PARK LMP |
| 91 | 20A | Horn |
| 92 | 40A | HD ACCY #2* |
| 93 | 40A | HD ACCY #1* |
| 94 | 10A | Dual USB Port |
| 95 | - | Spare* |
| 96 | 10A | PWR MIRROR SW |
| 97 | 20A | RADIO |
| 98 | 10A | SW BANK-HD ELEC / OFF ROAD |
| 99 | - | Spare* |
| 100 | - | Spare* |
| 101 | 30A | Drivetrain Control Module (DTCM) |
| 102 | 15A | TBM2 / DCSD Mod |
| 103 | 15A | HD ACCY #3 |
| 104 | 15A | Lumbar SW (Drive & Pass) |
| 105 | 10A | ICS / HVAC / ETC |
| 106 | 50A | Electronic Speed Control (ESC)-PUMP MTR |
| 107 | 20A | TRAILER TOW STOP / TURN LT |
| 108 | 15A | HD ACCY #4 |
| 109 | 20A | TRAILER TOW STOP/TURN RT |
| 110 | 30A | POWER INVERTER 150W |
| 111 | 20A | TRAILER TOW BACKUP |
* If Equipped
