Jeep Patriot 2013 Fuse Box Info
Fuse box location:
Fuse Box Diagram | Layout
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | - | - |
| 2 | 15A | AWD/4WD Control Module – If Equipped |
| 3 | 10A | Rear Center Brake Light Switch |
| 4 | 10A | Ignition Switch/ Occupant Classification Module |
| 5 | 20A | Trailer Tow – If Equipped |
| 6 | 10A | Power Mirror/ Steering Control Satellite Radio/Hands-Free Phone |
| 7 | 30A | Ignition Off Draw |
| 8 | 30A | Ignition Off Draw |
| 9 | 40A | Power Seats |
| 10 | 20A | Power Locks/Interior Lighting |
| 11 | 15A | Power Outlet |
| 12 | 20A | 115V AC Inverter – If Equipped |
| 13 | 20A | Cigar Lighter |
| 14 | 10A | Instrument Cluster |
| 15 | 40A | Radiator Fan |
| 16 | 15A | Dome Lamp/ Sunroof/Rear Wiper Motor |
| 17 | 10A | Wireless Control Module |
| 18 | 40A | Auto Shutdown Relay |
| 19 | 20A | Radio Amplifiers |
| 20 | 15A | Radio |
| 21 | 10A | Intrusion Module/ Siren – If Equipped |
| 22 | 10A | Heating, AC/ Compass |
| 23 | 15A | Auto Shutdown Relay |
| 24 | 15A | Power Sunroof – If Equipped |
| 25 | 10A | Heated Mirror – If Equipped |
| 26 | 15A | Auto Shutdown Relay |
| 27 | 10A | Airbag Control Module |
| 28 | 10A | Airbag Control Module/Occupant Classification Module |
| 29 | - | Hot Car (No Fuse Required) |
| 30 | 20A | Heated Seat – If Equipped |
| 31 | 10A | Headlamp Washer – If Equipped |
| 32 | 30A | Auto Shutdown Relay |
| 33 | 10A | J1962 Conn/ Powertrain Control Module |
| 34 | 30A | Antilock Brake Valve |
| 35 | 40A | Antilock Brake Pump |
| 36 | 30A | Headlamp/Washer Control/Smart Glass – If Equipped |
| 37 | 25A | Diesel Fuel Heater – If Equipped |
