Jaguar F-Type 2018 Fuse Box Info
Fuse box location:
Engine compartment fuse box:
Luggage compartment fuse box:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 30A | Right-side seat |
| 2 | - | - |
| 3 | - | - |
| 4 | 10A | Climate control |
| 5 | 5A | Telematics |
| 6 | - | - |
| 7 | 5A | Keyless locking |
| 8 | 5A | Body control module |
| 9 | 5A | Tire Pressure Monitoring System (TPMS), Overhead console |
| 10 | 5A | Brake pedal switch |
| 11 | 25A | Heated seats, Climate seats |
| 12 | 5A | Seat movement |
| 13 | 10A | Dynamic Stability Control (DSC), Center console switches |
| 14 | 10A | Dynamic Stability Control (DSC) |
| 15 | - | - |
| 16 | 5A | Vehicle immobilizer |
| 17 | 5A | Battery back-up sounder |
| 18 | - | - |
| 19 | 5A | Steering wheel |
| 20 | 25A | Climate control, Body control module |
| 21 | - | - |
| 22 | - | - |
| 23 | - | - |
| 24 | 5A | Headlamp leveling |
| 25 | 20A | Center console accessory socket |
| 26 | 20A | Cubby box accessory socket |
| 27 | 5A | Steering wheel |
| 28 | - | - |
| 29 | - | - |
| 30 | 5A | Body control module, Dashboard switches |
Engine compartment fuse box (Left side fuse box):
| Fuse/Relay N° | Rating | Functions |
| 1 | 5A | Diagnostic socket |
| 2 | - | - |
| 3 | - | - |
| 4 | 5A | Starter motor |
| 5 | 25A | Engine management |
| 6 | 5A | Engine management |
| 7 | 5A | Engine management |
| 8 | 10A | Engine management |
| 9 | - | - |
| 10 | 10A | Engine management |
| 11 | 20A | Engine management |
| 12 | 20A | Engine management |
| 13 | 20A | Engine management |
| 14 | 10A | Engine cooling system water pump |
| 15 | 5A | Active exhaust |
| 16 | 20A | Left-side LED headlight |
| 17 | 20A | Right-side LED headlight |
| 18 | 25A | Anti-lock Braking System (ABS) |
| 19 | 15A | Gear selector, Transmission |
| 20 | 30A | All Wheel Drive (AWD) system |
Engine compartment fuse box (Right side fuse box):
| Fuse/Relay N° | Rating | Functions |
| 1 | 25A | Headlamp wash |
| 2 | - | - |
| 3 | 15A | Horns |
| 4 | - | - |
| 5 | - | - |
| 6 | - | - |
| 7 | - | - |
| 8 | - | - |
| 9 | - | - |
| 10 | - | - |
Luggage compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 25A | Right-side door buttons |
| 2 | - | - |
| 3 | 30A | Electric Parking Brake (EPB) |
| 4 | - | - |
| 5 | - | - |
| 6 | 15A | Convertible roof |
| 7 | - | - |
| 8 | 25A | Left-side door buttons |
| 9 | 15A | Convertible roof |
| 10 | - | - |
| 11 | 10A | Rear-view camera, Rear-view mirror, Blind spot monitor |
| 12 | - | - |
| 13 | - | - |
| 14 | 2A | Electronic toll control |
| 15 | 25A | Powered tailgate |
| 16 | 30A | Electric Parking Brake (EPB) |
| 17 | - | |
| 18 | 30A | Fuel pump |
| 19 | 15A | Windshield washer pump |
| 20 | 10A | Audio video panel |
| 21 | 10A | Instrument panel |
| 22 | 5A | Body control module |
| 23 | - | - |
| 24 | - | - |
| 25 | - | - |
| 26 | - | - |
| 27 | - | - |
| 28 | 15A | Information and entertainment system |
| 29 | 5A | Dashboard switches |
| 30 | - | - |
